RULAND MANUFACTURING MRLS8-2-2-A Slit Coupling, 2 mm Bore Dia 1, 2 mm Bore Dia 2, 8 mm Coupling Outside Dia | CT9GWY 805HW4

RULAND MANUFACTURING MRLS8-2-2-A 2mm x 2mm Long Slit Coupling, Aluminum, Set Screw Style, 8.0mm OD, 14.5mm Lg.

Item: CT9GWYModel: MRLS8-2-2-ACross Ref: 805HW4
7 In Stock
Bore Dia.

Ships within 2 days via

€189.59
10.00% off
€170.64 /unit
Add To Cart
Request a Quote

Payment

Product Specifications:

Item Coupling
Angular Misalignment 2°
Application Medical And Scientific Equipment
Axial Motion 0.1 mm
Bore Dia. 1 2 mm
Bore Dia. 2 2 mm
Bore Tolerance 0 mm to 0.01 mm
Bore Type Round
Coupling Material Aluminum
Coupling Material Finish Surtec 650
Coupling Material Grade 7075
Coupling Outside Dia. 8 mm
Different Bore Sizes No
Dynamic Torque Non-reversing 0.3 N-m
Dynamic Torque Reversing 0.2 N-m
Features High Torsional Stiffness, Torque And Misalignment Capabilities
For Environment Medical
For Misalignment Type Angular, Axial, Parallel
Full Bearing Support Required Yes
Included Screws (4) Set Screw
Length Through Bore 1 5.2 mm
Length Through Bore 2 5.2 mm
Max. Bore Dia. 2 mm
Max. Operating Temp. 79.44°C
Max. Speed 24000 RPM
Min. Operating Temp. -78.89°C
Moment Of Inertia 0.00004945 lbs.-sq. in.
Number Of Locking Screws 4
Overall Length 14.5 mm
Parallel Misalignment 0.1 mm
Screw Material Stainless Steel
Screw Material Finish Bright
Screw Material Grade Grade 18-8, 300 Series
Screw Thread Size M1.6
Shaft Locking Type Set Screws
System Of Measurement Metric
Torsional Stiffness 0.2 N-m/deg.
Zero Backlash Yes

Shipping Info:

Ship height (cm)2.6
Ship length (cm)2
Ship width (cm)2
Country of OriginIE

Product Variants

ProductModelAxial MotionParallel MisalignmentTorsional StiffnessBore Dia. 1Bore Dia. 2Coupling Outside Dia.Different Bore SizesOverall LengthPrice
RULAND MANUFACTURING MRLS25-10-10-A Slit Coupling, 10 mm Bore Dia 1, 10 mm Bore Dia 2, 25 mm Coupling Outside Dia | CT9GCW 805HU8 MRLS25-10-10-A0.7 mm0.4 mm3.8 N-m/deg.10 mm10 mm25 mmNo34 mm€190.93
RULAND MANUFACTURING MRLS20-10-5-A Slit Coupling, 10 mm Bore Dia 1, 5 mm Bore Dia 2, 20 mm Coupling Outside Dia | CT9GDG 805HT9 MRLS20-10-5-A0.5 mm0.25 mm2.3 N-m/deg.10 mm5 mm20 mmYes26 mm€203.65
RULAND MANUFACTURING MRLS20-10-6-A Slit Coupling, 10 mm Bore Dia 1, 6 mm Bore Dia 2, 20 mm Coupling Outside Dia | CT9GDZ 805HU0 MRLS20-10-6-A0.5 mm0.25 mm2.3 N-m/deg.10 mm6 mm20 mmYes26 mm€181.07
RULAND MANUFACTURING MRLS25-10-6-A Slit Coupling, 10 mm Bore Dia 1, 6 mm Bore Dia 2, 25 mm Coupling Outside Dia | CT9GEA 805HU9 MRLS25-10-6-A0.7 mm0.4 mm3.8 N-m/deg.10 mm6 mm25 mmYes34 mm€190.93
RULAND MANUFACTURING MRLS20-10-8-A Slit Coupling, 10 mm Bore Dia 1, 8 mm Bore Dia 2, 20 mm Coupling Outside Dia | CT9GEE 805HU1 MRLS20-10-8-A0.5 mm0.25 mm2.3 N-m/deg.10 mm8 mm20 mmYes26 mm€181.07
RULAND MANUFACTURING MRLS25-10-8-A Slit Coupling, 10 mm Bore Dia 1, 8 mm Bore Dia 2, 25 mm Coupling Outside Dia | CT9GEL 805HV0 MRLS25-10-8-A0.7 mm0.4 mm3.8 N-m/deg.10 mm8 mm25 mmYes34 mm€190.93
RULAND MANUFACTURING MRLS25-12-10-A Slit Coupling, 12 mm Bore Dia 1, 10 mm Bore Dia 2, 25 mm Coupling Outside Dia | CT9GET 805HV1 MRLS25-12-10-A0.7 mm0.4 mm-12 mm10 mm25 mmYes34 mm€214.74
