PARKER 68VL-4-2 Compression Fitting, 1/4 Inch Outside Diameter, Brass
Item: AB3WYHModel: 68VL-4-2Cross Ref: 1VPT4
7 In Stock
Ships within 2 days via
10.00% off
€110.32 /pkg. of 10
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Compression Fitting |
| Application | Heavy Duty Truck, Trailer, Mobile |
| Basic Material | Metal |
| Basic Pipe Fitting Material | Metal |
| Basic Pipe Fitting Shape | Adapter |
| Body Material | Brass |
| Compatible Tube Material | Aluminum, Copper, Glass, Stainless Steel, Steel |
| Configuration Sub-type | Male Connector |
| Configuration Type | Tube To Male |
| Connection Type | NPTF x Straight Thread |
| Fitting Material | Brass |
| Fitting Side A Connection Type | Compression |
| Fitting Side A Tube Outer Diameter | 1/4" |
| Fitting Side B Connection Type | MNPT |
| Fitting Side B Pipe Size | 1/8" |
| Hex Size | 9/16" |
| Material | Brass |
| Max. Operating Pressure | 400 psi |
| Max. Operating Temp. | 135 Deg C |
| Max. Operating Temp. | 135°C |
| Max. Pressure | 400 psi |
| Maximum Operating Temperature | 275°F |
| Min. Operating Temp. | -34°C |
| Minimum Operating Temperature | 30°F |
| Nut Material | Brass |
| Operating Temp. Range | -30°F to +275°F |
| Overall Length | 1 5/32" |
| Product Datasheet | parker-68vl-4-2.pdf |
| Resistance Properties | Vibration Resistant |
| Ring Material | Fluorocarbon |
| Series | VIBRA LOK Series |
| Sleeve Material | Buna N, Fluorocarbon |
| Specific Application | Oil, Fuel And Coolant Lines On Engines |
| Specific Fitting Shape | Straight Adapter |
| Specific Pipe Fitting Shape | Connector |
| Style | Compression |
| System Of Measurement | Imperial |
| Temp. Range | -30°F to +275°F |
| Thread 1 Size | 1/8" |
| Thread 1 Type | NPT |
| Tube Outside Dia. | 1/4" |
| Tube Size | 1/4" |
Shipping Info:
| Ship weight (kg) | 0.23 |
| Ship height (cm) | 1.43 |
| Ship length (cm) | 2.94 |
| Ship width (cm) | 1.43 |
| HS code | 7419995010 |
| Country of Origin | US |
Documentation:
Product Variants
| Model | Tube Size | Max. Operating Temp. | Hex Size | Max. Operating Pressure | Pipe Size | Max. Pressure | Fitting Side A Tube Outer Diameter | Tube Outside Dia. | Pkg. Qty. | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 68VL-3-2 | 3/16" | 135°C | 1/2" | 400 psi | 1/8" | 400 psi | 3/16" | 0.188" | 10 | €126.82 | |
| 68VL-4-4 | 1/4" | 135°C | 9/16" | 400 psi | 1/4" | 400 psi | 1/4" | 1/4" | 10 | €166.42 | |
| 68VL-6-2 | 3/8" | 135°C | 11/16" | 225 psi | 1/8" | 225 psi | 3/8" | 3/8" | 10 | €187.15 | |
| 68VL-6-4 | 3/8" | 135°C | 11/16" | 225 psi | 1/4" | 225 psi | 3/8" | 3/8" | 10 | €189.98 | |
| 68VL-8-6 | 1/2" | 275°F | 7/8" | 200 psi | 3/8" | - | 1/2" | 3/8" | 1 | €27.61 | |
| 68VL-8-8 | 1/2" | 275°F | 7/8" | 200 psi | 1/2" | - | 1/2" | 1/2" | 1 | €34.34 |
