PARKER 0.31DXPSR03.00 Round Air Cylinder 5/16 Inch Bore 3 Inch Stroke
Item: AJ2DXAModel: 0.31DXPSR03.00Cross Ref: 49J533
7 In Stock
Ships within 2 days via
5.00% off
€60.95 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Air Cylinder |
| Air Cylinder Type | Round Body |
| Air Inlet | #10-32 UNF |
| Body Dia. | 1/2" |
| Body Material | Stainless Steel |
| Body Material Grade | Grade 304 |
| Bore Dia. | 0.312" , 5/16" |
| Color | Silver |
| Cushion Type | None |
| Cylinder Action | Double Acting |
| Cylinder Type | Round Body |
| End Cap Material | Aluminum |
| Features | Non-Switch Ready |
| Finish | Silver |
| For Fluid Type | Air |
| Inlet Gender | Female |
| Magnetic Piston | Non-Magnetic Piston |
| Max. Operating Pressure | 250 psi |
| Max. Operating Temp. | 165°F |
| Max. Pressure | 250 psi |
| Min. Operating Temp. | -10°F |
| Mounting Style | Nose, Pivot |
| Mounting Type | Nose, Pivot |
| No. Of Rods | 1 |
| Nose Mount Thread Size | 3/8"-24 |
| Overall Length | 5 3/5" |
| Piston Material | Aluminum |
| Piston Rod Material | Stainless Steel |
| Pivot Hole Dia. | 1/8" |
| Port Size | #10-32 |
| Repairable Cylinder | Non Repairable |
| Rod Dia. | 1/8" |
| Rod Rotation | Rotating Rod |
| Rod Thread Length | 3/8" |
| Rod Thread Size | #5-40 |
| Series | SR Series |
| Single Acting/double Acting | Double Acting |
| Spring Retraction Force | Not Applicable |
| Stroke | 3" |
| Stroke Length | 3" |
| System Of Measurement | Imperial |
| Tube Material | Stainless Steel |
| Type | Round Body |
Shipping Info:
| Ship weight (kg) | 0.04 |
| Ship height (cm) | 1.27 |
| Ship length (cm) | 14.22 |
| Ship width (cm) | 1.27 |
| Country of Origin | US |
Product Variants
| Product | Model | Stroke Length | Mounting | Rod Thread Length | Mounting Type | Bore Dia. | Stroke | Single Acting/double Acting | Cylinder Action | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
0.31BFDSR01.00 | - | - | 0.38" | Front Block | 0.312" | 1" | Double Acting | Double Acting | €77.32 | |
 |
0.31BFDSR02.00 | 2" | - | 3/8" | Front Block | 0.312" | 2" | Double Acting | Double Acting | €79.09 | |
|
0.31BFDSR03.00 | 3" | - | 3/8" | Front Block | 0.312" | 3" | Double Acting | Double Acting | €83.59 | |
|
0.31BFDSR04.00 | - | - | 0.38" | Front Block | 0.312" | 4" | Double Acting | Double Acting | €90.28 | |
 |
0.31DSR01.00 | 1" | - | 3/8" | Nose | 0.312" | 1" | Double Acting | Double Acting | €45.33 | |
|
0.31DSR02.00 | 2" | - | 3/8" | Nose | 0.312" | 2" | Double Acting | Double Acting | €47.58 | |
|
0.31DSR03.00 | 3" | - | 3/8" | Nose | 0.312" | 3" | Double Acting | Double Acting | €51.87 |
