MARTIN SPROCKET P368M20-1610 Sprocket, Bushed, 1610 Bushing, 1.625 Inch Max Bore, 36 Teeth, Steel
Item: AL4ZHQModel: P368M20-1610
7 In Stock
Ships within 2 days via
€234.38 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Sprocket |
| Bore Dia. | 1/2" to 1 5/8" |
| Bore Type | Taper Bushed |
| Bushing Type | 1610 |
| Face Width | 1 1/8" |
| Flange Dia. | 3.94" |
| Length | 1 1/8" |
| Material | Steel |
| No. Of Grooves | 36 |
| No. Of Teeth | 36 |
| Outside Dia. | 3.555" |
| Pitch | 8 mm |
| Pitch Dia. | 3.609" |
| Product Datasheet | martin-sprocket-10xl037.pdf |
| Suitable For Use With | RPP, RPP Plus, Hawk Pd, HTD belts |
| Type | Solid Type KF-1 |
Shipping Info:
| Ship weight (kg) | 0.77 |
| Ship height (cm) | 2.87 |
| Ship length (cm) | 9.04 |
| Ship width (cm) | 9.04 |
| Country of Origin | US |
Documentation:
Product Variants
| Product | Model | Bore Dia. | Pitch Dia. | Outside Dia. | Bore Type | Face Width | Type | Pitch | Bushing Type | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
P248M20-1108 | 1/2" to 1 1/8" | 2.406" | 2.352" | Taper Bushed | 1 1/8" | Solid Type KF-1 | 8 mm | 1108 | €200.35 | |
|
P268M20-1108 | 1/2" to 1 1/8" | 2.607" | 2.553" | Taper Bushed | 1 1/8" | Solid Type KF-1 | 8 mm | 1108 | €204.14 | |
 |
P288M20-1108 | 1/2" to 1" | 2.807" | 2.753" | TB Bushed | 1 1/8" | Solid Type KF-1 | 8 mm | 1108 | €207.92 | |
 |
P308M20-1210 | - | - | - | - | - | - | - | - | €215.47 | |
 |
P328M20-1210 | 1/2" to 1 1/4" | 3.208" | 3.154" | TB Bushed | 1 1/8" | Solid Type KF-1 | 8 mm | 1210 | €223.03 | |
 |
P348M20-1610 | 1/2" to 1 11/16" | 3.409" | 3.355" | TB Bushed | 1 1/8" | Solid Type KF-1 | 8 mm | 1610 | €226.81 | |
 |
P388M20-1610 | 1/2" to 1 11/16" | 3.81" | 3.756" | TB Bushed | 1 1/8" | Solid Type KF-1 | 8 mm | 1610 | €241.94 |
