MARTIN SPROCKET 120SF14H Roller Chain Sprocket, 120 Chain, Bushed QD, 14 Teeth, 6.741 Inch Pitch Dia., Steel
Item: AJ9AMCModel: 120SF14H
7 In Stock
Ships within 2 days via
€491.75 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Roller Chain Sprocket |
| Bore Type | Bushed |
| Bushing Part Number | SF |
| Bushing Size | SF |
| Chain Number | 120 |
| Chain Pitch | 1 1/2" |
| Construction | Solid |
| Construction Type | Solid |
| For Chain Number | 120 |
| For Chain Pitch | 1 1/2" |
| Hardened Teeth | 1 |
| Hub Configuration | B |
| Hub Diameter | 4 3/4" |
| Hub Outside Dia. | 4 3/4" |
| Individually Packaged | No |
| Length Through Bore | 2 1/16" |
| Length Thru Bore | 1 1/4" |
| Material | Steel |
| Max. Bore Size | 2 15/16" |
| Min. Bore Size | 1/2" |
| No. Of Teeth | 14 |
| Number Of Chain Rows | 1 |
| Number Of Teeth | 14 |
| Outside Dia. | 7.472" |
| Pitch | 1 1/2" |
| Pitch Dia. | 6.7409" |
| Pitch Diameter | 6.741" |
| Single Strand Tooth Thickness | 0.924" |
| Storage Dimension Height | 1 1/4" |
| Storage Dimension Length | 7.472" |
| Storage Dimension Width | 7.472" |
Shipping Info:
| Ship weight (kg) | 3.24 |
| Ship height (cm) | 5.23 |
| Ship length (cm) | 18.97 |
| Ship width (cm) | 18.97 |
| Country of Origin | US |
Product Variants
| Model | Number Of Teeth | Pitch Dia. | Outside Dia. | Length Through Bore | Bushing Type | For Chain Pitch | For Chain Number | Bore Type | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| 120SF12H | 12 | 5.7956" | 6.498" | 2 1/16" | Type SF QD | 1 1/2" | 120 | Bushed | €395.38 | |
| 120SF13H | 13 | 6.2679" | 6.986" | 1 1/4" | QD SF | 1 1/2" | 120 | Bushed | €448.39 | |
| 120SF15H | 15 | 7.2146" | 7.957" | 2 1/16" | Type SF QD | 1 1/2" | 120 | Bushed | €545.27 | |
| 120E16H | 16 | 7.689" | 8.441" | 2 5/8" | Type E QD | 1 1/2" | 120 | Bushed | €474.99 | |
| 120E17H | 17 | 8.1633" | 8.924" | 2 5/8" | Type E QD | 1 1/2" | 120 | Bushed | €508.36 | |
| 120E18H | 18 | 8.6382" | 9.407" | 2 5/8" | Type E QD | 1 1/2" | 120 | Bushed | €527.71 | |
| 120E19H | 19 | 9.1133" | 9.889" | 2 5/8" | Type E QD | 1 1/2" | 120 | Bushed | €566.32 |
