MACROMATIC TR-51222-15 Time Delay Relay, 120V AC/DC, 10A
30 Min
Triggered On Delay
120VAC, 125VDC
Get it by Tuesday, Sep 1
€79.92 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Time Delay Relay |
| Ac Voltage | 120V AC |
| Adjustment Operator | Knob |
| Contact | DPDT |
| Contact Rating | 10A |
| Contact Rating (a) | 10A |
| Contacts | DPDT |
| Dc Voltage | 120V DC |
| Eu Rohs Indicator | Yes |
| Family Series | Macromatic Relays, TR-5 Series |
| Gross Weight | 0 lbs. |
| Max. Time | 30 min. |
| Mounting Type | Socket |
| Multi-function | No |
| Nominal Coil Voltage | 120V AC/125V DC |
| Output Amps | 10A |
| Product Datasheet | macromatic-tr-50222-04.pdf |
| Series | TR-5 Series |
| Termination | 11 Pin |
| Time Range Adjustment | Onboard |
| Timer | 0 min. to 1 min., 0 min. to 2 min., 0 min. to 3 min., 0 min. to 5 min., 0 min. to 10 min., 0 min. to 15 min., 0 min. to 30 min. |
| Timing Range | 0.3 - 30 Minutes |
Shipping Info:
| Ship weight (kg) | 0.68 |
| Ship height (cm) | 6.1 |
| Ship length (cm) | 7.62 |
| Ship width (cm) | 4.32 |
| Country of Origin | US |
Documentation:
Product Variants
| Product | Model | Ac Voltage | Dc Voltage | Coil Voltage | Input Voltage | Max. Time | Timer | No. Of Pins | Coil Rating | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
TR-50222-04 | 120V AC | 120V DC | 120V AC | 120V AC/DC | 5 sec. | - | 8 | 2 VA | €46.19 | |
 |
TR-50222-10 | 120V AC | 120V DC | 120V AC | 120V AC/DC | 180 sec. | - | 8 | 2 VA | €51.98 | |
 |
TR-50222-12 | 120V AC | 120V DC | 120V AC | 120V AC/DC | 300 sec. | - | 8 | 2 VA | €46.93 | |
 |
TR-50222 | - | - | 120V AC | 120V AC/DC | - | - | - | 2 VA | €46.86 | |
 |
TR-50522-05 | 120V AC | 120V DC | 120V AC | 120V AC/DC | 10 sec. | - | 8 | 2 VA | €48.42 | |
 |
TR-50522-10 | 120V AC | 120V DC | 120V AC | - | 180 sec. | - | 8 | 2 VA | €47.08 | |
 |
TR-50522-12 | 120V AC | 120V DC | 120V AC | 120V AC/DC | 300 sec. | - | 8 | 2 VA | €46.23 |
