LEVITON AFTR1-W Receptacle, Decorator Duplex, 5-15R, 15 A, 125V AC, White, 2 Poles, Screw Terminals
Item: CR9JCCModel: AFTR1-WCross Ref: 792U75
7 In Stock
Ships within 2 days via
10.00% off
€71.74 /unit
This product can only be shipped in multiples of 10Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Receptacle |
| Afci | Yes |
| Amps | 15A |
| Body Material | Polycarbonate |
| Compatible With Series | AFTR1 Series |
| Connection Orientation | Straight |
| Contact Material | Brass |
| Cover Type | No Cover |
| Current Rating | 15A |
| Gfci | No |
| Grade | General Use |
| Grounding | Grounded |
| Housing Color | White |
| Hp | 1 hp |
| Includes | Screws, Self Grounding Clip |
| Max. Operating Temp. | 66°C |
| Maximum Operating Temperature | 150.8°F |
| Maximum Wire Size | 10 AWG |
| Min. Wire Size | 14 AWG |
| Minimum Operating Temperature | -31°F |
| Mounting Type | Flush |
| Nema Receptacle Configuration | NEMA 5-15R |
| Number Of Outlets | 2 |
| Number Of Poles | 2 |
| Number Of Wires | 3 |
| Phase | Single |
| Polarized | Yes |
| Receptacle Type | Decorator Duplex |
| Reset Type | Automatic |
| Reverse Service | Yes |
| Self Testing | No |
| Special Resistance | Tamper Resistant |
| Standards | Csa Certified, Nema Wd-1, Nema Wd-6, Ul Listed |
| Surge Protection | No |
| Ul 94 Flammability Rating | V-2 |
| Visual Indicator Lights | Power Connected |
| Voltage | 125V AC |
| Voltage Rating | 125V AC |
| Wall Plate Material | Nylon |
| Wire Connection Location | Back, Side |
| Wire Connection Type | Screw Terminals |
Shipping Info:
| Ship weight (kg) | 0.17 |
| Ship height (cm) | 10.69 |
| Ship length (cm) | 3.23 |
| Ship width (cm) | 2.54 |
| Country of Origin | CN |
Product Variants
| Product | Model | Surge Protection | Housing Color | Current Rating | Nema Receptacle Configuration | Gfci | Grounding | Amps | Color | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
AFTR1-GY | No | Gray | 15A | NEMA 5-15R | No | Grounded | 15A | Gray | €79.70 | |
 |
AFTR1-I | Yes | Ivory | - | NEMA 5-15R | Yes | Grounded | 15A | Ivory | €79.70 | |
 |
AFTR1-T | No | Light Almond | 15A | NEMA 5-15R | No | Grounded | 15A | Light Almond | €79.70 | |
 |
AFTR2-E | No | Black | 20A | NEMA 5-20R | No | Grounded | 20A | Black | €84.93 | |
 |
AFTR2 | No | Brown | 20A | NEMA 5-20R | No | Grounded | 20A | Brown | €100.45 | |
 |
AFTR2-GY | No | Gray | 20A | NEMA 5-20R | No | Grounded | 20A | Gray | €83.09 | |
 |
AFTR2-I | Yes | Ivory | - | NEMA 5-20R | Yes | Grounded | 20A | Ivory | €73.15 |
