LEESON 5KH39EN2552X H439 / 5KH39EN2552BX Jet Pump Motor, 0.33 HP, 1 Phase, 60 Hz, 115V, 3600 RPM
Get it by Tuesday, Dec 23
€ 24,99 Flat Shipping + VAT € 24,99 flat shipping is applicable on orders with an aggregate weight less than 10kg. Orders exceeding 10kg will be charged default shipping rates.
10.00% off
€172.37 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Jet Pump Motor |
| Ambient (c) | 50 |
| Bearing Type | Ball |
| Body Dia. | 5 3/5" |
| Bolt Circle Dia. | 4 1/2" |
| Duty Cycle | Continuous |
| Frame | 56C |
| Frame Material | Steel |
| Frequency | 60 Hz |
| Full Load Amps | 6.2A |
| Hazardous Location Class | 2C |
| Hp | 1/3 hp |
| Ins. Class | Class B |
| Lead Length | 4", 6" |
| Length Less Shaft | 9 1/8" |
| Max. Ambient Temp. | 50°C |
| Motor Application | Pump |
| Motor Bearings | Ball |
| Motor Design | Split-Phase |
| Motor Enclosure Design | Open Dripproof |
| Motor Frame Material | Steel |
| Motor Mounting Position | All Angle |
| Motor Mounting Type | Face |
| Motor Service Factor | 1.75 |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | CCWSE |
| Motor Sub Application | Jet Pump |
| Motor Thermal Protection | Automatic |
| Motor Type | Split Phase |
| Mounting Type | Face |
| Nameplate Rpm | 3450 RPM |
| Nominal Efficiency | 54.5% |
| Number Of Speeds | 1 |
| Orientation | Horizontal, Vertical |
| Overall Length | 11" |
| Phase | 1 |
| Service Factor | 1.75 |
| Shaft Dia. | 5/8" |
| Shaft Length | 1 7/8" |
| Shaft Material | Stainless Steel |
| Thermal Protection | Automatic |
| Usable @ 200v | No |
| Voltage | 115V AC |
| Weight | 18 lbs. |
Shipping Info:
| Ship weight (kg) | 8.1 |
| Ship height (cm) | 19.05 |
| Ship length (cm) | 44.93 |
| Ship width (cm) | 19.53 |
| HS code | 8501404040 |
| Country of Origin | MX |
Product Details:
- Starting Type: Switch and Mech
- KVA Code: S
- Drive End Bearing: LOCKED
- Opposite End Bearing: BALL
- Drive End Bearing Size: 6203
- Opposite End Bearing Size: 6203
