LEESON 110420.00 C6K17FC2L Single Phase Motor | AJ2QCZ C6K17FC2L

LEESON 110420.00 C6K17FC2L General Purpose Motor, 1.50 HP, 1 Phase, 60 Hz, 115/230V, 1800 RPM

Item: AJ2QCZModel: 110420.00Cross Ref: 773N27 / C6K17FC2L
Check Availability
In Stock
Output KW
Frame

Get it by Thursday, May 21

€1,176.42
5.00% off
€1,117.60 /unit
Add To Cart
Request a Quote

Payment

Delivery

Product Specifications:

Item Single Phase Motor
Ambient Temp. 40°C
Amps 17.2/8.6A
Code J
Conduit Box Position F1
Design Code L
Drive End Bearing Size 6203
Drive End Bearing Type Ball
Duty Cycle Continuous
Efficiency 79%
Electrical Type Capacitor Start, Capacitor Run
Enclosure Type Tefc
Frame 56C
Frame Length 7 1/2"
Frame Material Rolled Steel
Frame Type 56C
Frequency 60 Hz
Full Load Amps 17.2/8.8-8.6A
Grease Type Polyrex EM
Height 10 22/25"
Hp 1 1/2 hp
Insulation Class Class B
Ip Code IP54
Kva Code J
Kw 1.1 kW
Length 14 11/25"
Lubrication Polyrex EM
Max. Rpm 1725 RPM
Motor Enclosure Design Totally Enclosed Fan Cooled
Motor Orientation Horizontal
Motor Shaft Design Keyed
Motor Shaft Rotation Selective Counter Clockwise
Motor Type Capacitor Start
Mounting Type C Face, Footless
Nameplate Rpm 1800 RPM
Nema Design J, L
No. Of Poles 4
No. Of Speeds 1
Opp. Drive End Bearing Size 6203
Opp. Drive End Bearing Type Ball
Output Kw 1.12 kW
Packaging B
Phase 1
Power Factor 73
Product Datasheet leeson-110420-00.pdf
Resistance Main 1.4 ohms
Rpm 1700-1800 RPM
Service Factor 1
Shaft Dia. 5/8"
Shaft Length 1 22/25"
Shaft Type NEMA 56
Starting Method Across The Line
Thermal Protection No Protection
Type KF
Voltage 115/208-230V
Width 10 11/25"

Shipping Info:

Ship weight (kg) 17.55
Ship height (cm)27.64
Ship length (cm)36.68
Ship width (cm)26.52
Country of OriginUS

Product Details:

    • Eff 100%: 79
    • Bearing OPE: 6203
    • Bearing PE: 6203
    • Nameplate: 993500
    • Winding: K634278
    • GROUP: 3
    • Paint: BLUE - LEESON (ENAMEL)

Documentation:

Datasheet

Product Variants

ProductModelVoltageFull Load AmpsHpPhaseService FactorMounting TypeFrequencyNameplate RpmPrice
MARATHON MOTORS 5KCR46JN0087Y General Purpose Motor Carbon Steel Tefc 1/3 Hp 1725/1425 Rpm 56c | AA9ZKL 1K124 / E255 5KCR46JN0087Y115/230V AC3.8-4/1.9-2A1/3 hp11.35Face/Base60 Hz1725 RPM€933.52
MARATHON MOTORS 5KCR46MN0055Y General Purpose Motor Carbon Steel Tefc 1/2 Hp 1725/1425 Rpm 56c | AA9ZKP 1K127 / E264 5KCR46MN0055Y115/230V AC5.6-5.8/2.8-2.9A1/2 hp11.25Face/Base50/60 Hz1725 RPM€841.44
MARATHON MOTORS 5KCR46MN0093 General Purpose Motor Carbon Steel Tefc 1/2 Hp 1725/1425 Rpm 56c | AA9ZKQ 1K128 / E265 5KCR46MN0093115/230V AC5.6-5.8/2.8-2.9A1/2 hp11.25Face60 Hz1725 RPM€814.28
MARATHON MOTORS 5KCR46MN0055X General Purpose Motor Carbon Steel Tefc 1/2 Hp 1725/1425 Rpm 56c | AA9ZKR 1K129 / E266 5KCR46MN0055X115/230V AC5.6-5.8/2.8-2.9A1/2 hp11.25Face/Base60 Hz1725 RPM€956.68
MARATHON MOTORS 5KCR49PN0099X General Purpose Motor Carbon Steel Tefc 3/4 Hp 1725/1425 Rpm 56c | AA9ZKV 1K132 / E275 5KCR49PN0099X115/230V AC8.8-9/4.4-4.5A3/4 hp11.25Face/Base50/60 Hz1725 RPM€1,116.48
MARATHON MOTORS 5KCR49UN0107 General Purpose Motor Carbon Steel Tefc 1 Hp 1725/1425 Rpm 56c | AA9ZKX 1K134 / EG283 5KCR49UN0107115/230V AC11.4-11.8/5.7-5.9A1 hp11.15Face60 Hz1725 RPM€1,031.58
MARATHON MOTORS 5KCR49UN0106X General Purpose Motor Carbon Steel Tefc 1 Hp 1725/1425 Rpm 56c | AA9ZKY 1K135 / EG284 5KCR49UN0106X115/230V AC11.4-11.8/5.7-5.9A1 hp11.15Face/Base60 Hz1725 RPM€1,060.60
