LEESON 056T34F99017 D394A / 56T34F99017A AC Induction Motor, General Purpose, Inverter Rated And 4-In-1, 1-1/2Hp, 3-Phase
Get it by Friday, Jul 3
€726.62 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | AC Motor |
| Ambient Temp. | 40°C |
| Amps | 4/2, 3.4/1.7A |
| Assembly/box Mounting | F1 Only |
| Ce | Y |
| Csa | Y |
| Design Code | B |
| Drive End Bearing | Ball |
| Drive End Bearing Size | 6203 |
| Duty | Continuous |
| Efficiency | 84 & 85.5 % |
| Electrical Type | Squirrel Cage Induction Run |
| Enclosure | Totally Enclosed Fan Cooled |
| Frame Length | 8.06" |
| Frame Material | Rolled Steel |
| Frame Size | 56C |
| Frequency | 60/50 Hz |
| Insulation Class | Class F |
| Ip Code | 43 |
| Kva Code | M |
| Motor Orientation | Horizontal |
| Mounting | Bolt-On Base |
| No. Of Speed | 1 |
| Opp Drive End Bearing | Ball |
| Opp Drive End Bearing Size | 6203 |
| Output Hp | 1.50 hp, 1 hp |
| Output Kw | 1.1/0.75 kW |
| Overall Length | 13.31" |
| Phase | 3 |
| Poles | 2 |
| Power Factor | 83.5 |
| Product Datasheet | marathon-motors-d391.pdf |
| Resistance Main | 9.27 ohms |
| Rotation | Reversible |
| Service Factor | 1.15 and 1.15 |
| Shaft Dia. | 0.625" |
| Shaft Extension | 2.06" |
| Shaft Type | NEMA 56 |
| Speed | 3450/2850 RPM |
| Starting Method | Across The Line |
| Thermal Protection | No Protection |
| Ul | Recognized |
| Voltage | 230/460/190/380V |
Shipping Info:
| Ship weight (kg) | 16.65 |
| Ship height (cm) | 20.62 |
| Ship length (cm) | 40.94 |
| Ship width (cm) | 26.04 |
| Country of Origin | MX |
Documentation:
Product Variants
| Product | Model | Frequency | Voltage | Hp | Full Load Amps | Phase | Service Factor | Mounting Type | Motor Type | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
5KCR46JN0087Y | 60 Hz | 115/230V AC | 1/3 hp | 3.8-4/1.9-2A | 1 | 1.35 | Face, Base | Capacitor Start | €942.30 | |
 |
5KCR46MN0055Y | 60 Hz | 115/230V AC | 1/2 hp | 5.6-5.8/2.8-2.9A | 1 | 1.25 | Face, Base | Capacitor Start, Run | €841.44 | |
 |
5KCR46MN0093 | 60 Hz | 115/230V AC | 1/2 hp | 5.6-5.8/2.8-2.9A | 1 | 1.25 | Face | Capacitor Start, Run | €814.28 | |
 |
5KCR46MN0055X | 60 Hz | 115/230V AC | 1/2 hp | 5.6-5.8/2.8-2.9A | 1 | 1.25 | Face, Base | Capacitor Start, Run | €886.09 | |
 |
5KCR49PN0099X | 60 Hz | 115/230V AC | 3/4 hp | 8.8-9/4.4-4.5A | 1 | 1.25 | Face, Base | Capacitor Start, Run | €1,094.78 | |
 |
5KCR49UN0107 | 60 Hz | 115/230V AC | 1 hp | 11.4-11.8/5.7-5.9A | 1 | 1.15 | Face | Capacitor Start | €1,031.58 | |
 |
5KCR49UN0106X | 60 Hz | 115/230V AC | 1 hp | 11.4-11.8/5.7-5.9A | 1 | 1.15 | Face, Base | Capacitor Start, Run | €1,060.60 |
