LEESON 048A11O1875 X039 / 48A11O1875A Fan and Blower Motor, 0.75 HP, 1 Phase, 60 Hz, 460V, 1200 RPM
Get it by Tuesday, Dec 23
€ 24,99 Flat Shipping + VAT € 24,99 flat shipping is applicable on orders with an aggregate weight less than 10kg. Orders exceeding 10kg will be charged default shipping rates.
10.00% off
€548.79 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | HVAC Motor |
| Ambient (c) | 40°C |
| Ambient Temp. | 40°C |
| Assembly | F1 Only |
| Bearing Type | Ball |
| Body Dia. | 5 11/16" |
| Bolt Circle Dia. | 5 1/8" |
| Capacitor Required | 2MDV9 |
| Conduit Box Location | Exterior |
| Conduit Box Position | F1 |
| Duty Cycle | Continuous |
| Efficiency | 64% |
| Enclosure Type | Open Air Over |
| Extended Thru-bolts | Yes |
| Frame | 48Z |
| Frequency | 60 Hz |
| Full Load Amps | 2.1A |
| Full Load Efficiency | 64% |
| Hp | 3/4 hp |
| Insulation Class | Class B |
| Length Less Shaft | 6 3/8" |
| Manufacturers Warranty Length | 1 yr. |
| Max. Ambient Temp. | 40°C |
| Motor Application | HVAC/R |
| Motor Bearings | Ball |
| Motor Design | Permanent Split Capacitor |
| Motor Enclosure Design | Open Air Over |
| Motor Frame Material | Steel |
| Motor Mounting Position | Horizontal |
| Motor Mounting Type | Ring, Stud |
| Motor Service Factor | 1 |
| Motor Shaft Design | Flat |
| Motor Shaft Rotation | CW/CCW |
| Motor Sub Application | Direct Drive Fan/Blower |
| Motor Thermal Protection | Automatic |
| Motor Type | Permanent Split Capacitor |
| Mounting Type | Extended Studs, Footless |
| Nameplate Rpm | 1075 RPM |
| Nema Design | No Design Code |
| Nominal Efficiency | 0.64% |
| Number Of Shafts | 1 |
| Number Of Speeds | 2 |
| Overall Length | 12 7/16" |
| Phase | 1 |
| Power | 0.56 kW |
| Service Factor | 1 |
| Shaft Dia. | 1/2" |
| Shaft Length | 6 1/16" |
| Shaft Orientation | Horizontal |
| Standards | Csa (Lr2025), Ul (E6312) |
| Stud Size | #10-32 |
| Thermal Protection | Automatic |
| Usable @ 200v | No |
| Usable @ 208v | No |
| Voltage | 460V AC |
| Warranty | 1 yr. |
| Weight | 19 lbs. |
Shipping Info:
| Ship weight (kg) | 8.55 |
| Ship height (cm) | 17.63 |
| Ship length (cm) | 33.66 |
| Ship width (cm) | 17.78 |
| HS code | 8501404040 |
| Country of Origin | MX |
Product Details:
- Starting Type: PSC 2 SPEED
- KVA Code: B
- Drive End Bearing: BALL
- IP Code: 10
- Opposite End Bearing: BALL
- Drive End Bearing Size: 6203
- Opposite End Bearing Size: 6203
Product Variants
| Product | Model | Hp | Motor Enclosure Design | Motor Mounting Type | Frame | Shaft Length | Mounting Type | Efficiency | Power | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
048A11O1874 | 1/2 hp | Open Dripproof | C Face, Footless | 48Y | 6.06" | Round | Not Applicable | 0.37 kW | €729.49 |
