HUBBELL WIRING DEVICE-KELLEMS HBL2730 Flush Receptacle, 30A, 3-Phase, Delta, 480VAC, 3-Pole, 4-Wire Grounding
Item: AE7QYZModel: HBL2730Cross Ref: 6A658
7 In Stock
NEMA L16-30R
Black
14400 W
Ships within 2 days via
10.00% off
€114.36 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Receptacle |
| Amps | 30A |
| Color | Black |
| Connectivity | Back And Side Wired Screw Terminals |
| Dielectric Strength | Withstands 2,000V minimum |
| Grade | Grade Industrial |
| Material | Nylon |
| Max. Hp | 10 hp |
| Mounting | Screw Mounting |
| Mounting Type | Flush |
| Nema Rating | NEMA L16-30R |
| Number Of Poles | 3 |
| Number Of Wires | 4 |
| Operating Temp. | -40°C to +85°C |
| Phase | 3 |
| Product Datasheet | hubbell-wiring-device-kellems-hbl2730.pdf |
| Type | Non Shrouded |
| Wattage | 14400 W |
| Width | 1.7" |
| Wire Size | 16 AWG to 8 AWG |
| Wire Type | Standard |
Shipping Info:
| Ship weight (kg) | 0.11 |
| Ship height (cm) | 3.33 |
| Ship length (cm) | 8.33 |
| Ship width (cm) | 4.32 |
| HS code | 8536698000 |
| Country of Origin | US |
Documentation:
Product Variants
| Product | Model | Number Of Poles | Number Of Wires | Phase | Current Rating | Voltage Rating | Ip Rating | Resistance Properties | Material | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
HBL2330 | 2 | 3 | 1 | 20A | 277V AC | IP20 | Corrosion Resistant | Nylon | €70.70 | |
 |
HBL2510 | 4 | 5 | 3 | 20A | 120/208V AC | IP20 | Corrosion Resistant | Nylon | €115.90 | |
 |
HBL2810 | 4 | 5 | 3 | 30A | 120/208V AC | IP20 | Corrosion Resistant | Nylon | €165.66 | |
 |
HBL2350 | 2 | 3 | 1 | 20A | 600V AC | IP20 | Corrosion Resistant | Nylon | €84.16 | |
 |
HBL2440 | 4 | 4 | 3 | 20A | 120/208V AC | IP30 | Corrosion Resistant | Nylon | €101.32 | |
 |
HBL2740 | 3 | 4 | 3 | - | - | - | - | Nylon | €133.52 | |
 |
HBL2750 | 4 | 4 | 3 | 30A | 120/208V AC | IP20 | Corrosion Resistant | Thermoplastic | €158.00 |
