HONEYWELL V5862A2070 Threaded Globe Valve, 3/4 FNPT, 4.9 Cv
Item: CH6RWDModel: V5862A2070Cross Ref: 279A75
7 In Stock
Ships within 2 days via
10.00% off
€175.07 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Threaded Globe Valve |
| Ansi Rating | ANSI Leakage Class Iv |
| Body Material | Brass |
| Body Pattern | Two-Way |
| Cartridge Material | Brass |
| Coefficient Of Volume | 4.9 |
| Compatible With Series | V58 Series |
| Configuration | Straight-Thru |
| Connection Size | 3/4" |
| Connection Type | NPT |
| Cv Flow Rate | 4.9 |
| Flow Characteristic | Equal Percentage |
| Fluid Service | Water Glycol Solution to 50% |
| Fluid Temperature - Maximum | 230°F |
| Fluid Temperature - Minimum | 36°F |
| Height | 2.469" |
| Includes Actuator | Actuator Not Included |
| Leakage Rate | 0.01% |
| Max. Water Temp. | 36 to 248 |
| Number Of Ways | 2 |
| Overall Depth | 1 3/16" |
| Overall Height | 2 15/32" |
| Overall Length | 3 7/32" |
| Port Connection Gender | Female |
| Port Connection Size | 3/4" |
| Port Connection Type | NPT |
| Rangeability | 100:1 |
| Safe Working Steam Pressure | 40.5 |
| Seat Material | Brass |
| Specific Valve Action | Stem Down To Close |
| Stem Material | Stainless Steel |
| Stem Travel | 1/4" |
| Type | 2 Way |
| Valve Action | Normally Open, Normally Closed |
Shipping Info:
| Ship weight (kg) | 0.16 |
| Ship height (cm) | 6.27 |
| Ship length (cm) | 8.18 |
| Ship width (cm) | 3.02 |
| Country of Origin | DE |
Product Variants
| Product | Model | Seat Material | Body Pattern | Configuration | Coefficient Of Volume | Number Of Ways | Height | Body Material | Connection Size | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
V5011N1008 | 1/2" | Stainless Steel | 337°F | 6 5/8" | 3 1/4" | 1 9/16" | Straight-Thru | 0.05% | €375.05 | |
 |
V5011N1016 | 1/2" | Stainless Steel | 337°F | 6 5/8" | 3 1/4" | 1 9/16" | Straight-Thru | 0.05% | €614.23 | |
|
V5011N1024 | 1/2" | Stainless Steel | 337°F | 6 5/8" | 3 1/4" | 1 9/16" | Straight-Thru | 0.05% | €440.84 | |
 |
V5011N1032 | 1/2" | Stainless Steel | 337°F | 6 5/8" | 3 1/4" | 1 9/16" | Straight-Thru | 0.05% | €340.07 | |
|
V5011N1040 | 1/2" | Stainless Steel | 337°F | 6 5/8" | 3 1/4" | 1 9/16" | Straight-Thru | 0.05% | €359.41 | |
|
V5011N1057 | 3/4" | Stainless Steel | 337°F | 6 5/8" | 3 1/4" | 1 9/16" | Straight-Thru | 0.05% | €367.42 | |
|
V5011N1065 | 1" | Stainless Steel | 337°F | 6 5/8" | 4 1/16" | 1 9/16" | Straight-Thru | 0.05% | €484.60 |
