HONEYWELL V5011N1065 Threaded Globe Valve, 2-Way, Direct Acting, 1 Inch FNPT
Item: CD3RVDModel: V5011N1065Cross Ref: 279A76
7 In Stock
Ships within 2 days via
10.00% off
€436.13 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Threaded Globe Valve |
| Ansi Rating | ANSI Class 150 |
| Body Material | Brass |
| Body Pattern | Two-Way |
| Coefficient Of Volume | 11.7 |
| Compatible With Series | V5011N Series |
| Configuration | Straight-Thru |
| Cv Flow Rate | 11.7 |
| Description/special Features | Valve Designs Provide Equal Percentage Characteristics Of Flow For Close Control Of Water, And Linear Characteristic Of Flow For Close Control Of Steam. |
| Flow Characteristic | Equal Percentage |
| Fluid Service | Steam, Water |
| Fluid Temperature - Maximum | 337°F |
| Fluid Temperature - Minimum | 36°F |
| Includes Actuator | Actuator Not Included |
| Installation Orientation | Vertical |
| Leakage Rate | 0.05% |
| Number Of Ways | 2 |
| Overall Depth | 1 9/16" |
| Overall Height | 6 5/8" |
| Overall Length | 4 1/16" |
| Packing Material | PTFE |
| Port Connection Gender | Female |
| Port Connection Size | 1" |
| Port Connection Type | NPT |
| Rangeability | 50:1 |
| Safe Working Steam Pressure | 40.5 |
| Seat Material | Stainless Steel |
| Specific Valve Action | Stem Down To Close |
| Stem Material | Stainless Steel |
| Trim Material | Brass |
| Valve Action | Normally Open, Normally Closed |
Shipping Info:
| Ship weight (kg) | 1.6 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 2.54 |
| Ship width (cm) | 2.54 |
Product Variants
| Product | Model | Seat Material | Body Pattern | Configuration | Coefficient Of Volume | Number Of Ways | Height | Body Material | Connection Size | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
V5011N1008 | 1/2" | Stainless Steel | 337°F | 6 5/8" | 3 1/4" | 1 9/16" | Straight-Thru | 0.05% | €375.05 | |
 |
V5011N1016 | 1/2" | Stainless Steel | 337°F | 6 5/8" | 3 1/4" | 1 9/16" | Straight-Thru | 0.05% | €614.23 | |
|
V5011N1024 | 1/2" | Stainless Steel | 337°F | 6 5/8" | 3 1/4" | 1 9/16" | Straight-Thru | 0.05% | €440.84 | |
|
V5011N1032 | 1/2" | Stainless Steel | 337°F | 6 5/8" | 3 1/4" | 1 9/16" | Straight-Thru | 0.05% | €340.07 | |
|
V5011N1040 | 1/2" | Stainless Steel | 337°F | 6 5/8" | 3 1/4" | 1 9/16" | Straight-Thru | 0.05% | €359.41 | |
|
V5011N1057 | 3/4" | Stainless Steel | 337°F | 6 5/8" | 3 1/4" | 1 9/16" | Straight-Thru | 0.05% | €367.42 | |
|
V5011N1073 | 1 1/4" | Stainless Steel | 337°F | 7 11/32" | 4 3/16" | 1 9/16" | Straight-Thru | 0.05% | €607.85 |
