GENERAL ELECTRIC THQB32015 Bolt On Circuit Breaker Thqb 15 Amp 240vac 3p 10kaic@240v
Item: AG8WAGModel: THQB32015Cross Ref: 3HXW2
7 In Stock
Ships within 2 days via
10.00% off
€657.25 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Bolt On Circuit Breaker |
| Ac Voltage Rating | 120/240V AC |
| Aic Rating | 10 kAIC @ 240V |
| Amps | 15A |
| Circuit Breaker Actuator | Toggle |
| Circuit Breaker Mounting Style | Bolt On |
| Circuit Breaker Type | Standard |
| Dc Voltage Rating | Not Rated |
| Depth | 3.28" |
| For Use With | Lighting Panels, Load Centers |
| Frame Size | 100A, THQ |
| Frame Type | THQB |
| Length | 3.53" |
| Max. Air Rating | 10 kA At 120/240V AC |
| Max. Wire Size | 8 AWG |
| Min. Wire Size | 14 AWG |
| Number Of Poles | 3 |
| Phase | Three |
| Terminal Connection | Screw Clamp |
| Voltage | 240V |
| Voltage Type | AC |
| Width | 1" |
Shipping Info:
| Ship weight (kg) | 0.51 |
| Ship height (cm) | 8.33 |
| Ship length (cm) | 6.03 |
| Ship width (cm) | 7.62 |
Product Variants
| Model | Number Of Poles | Ac Voltage Rating | Amps | Circuit Breaker Type | Phase | Aic Rating | Min. Wire Size | Max. Wire Size | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| THQB32020 | 3 | 120/240V AC | 20A | Standard | Three | - | 14 AWG | 8 AWG | €659.23 | |
| THQB32030 | 3 | 120/240V AC | 30A | Standard | Three | - | 14 AWG | 8 AWG | €685.28 | |
| THQB32070 | 3 | 120/240V AC | 70A | Standard | Three | - | 8 AWG | 1/0 AWG | €805.86 | |
| THQB32080 | 3 | 120/240V AC | - | Standard | Three | - | 6 AWG | 1/0 AWG | €1,055.71 | |
| THQB32100 | 3 | 120/240V AC | 100A | Standard | Three | - | 6 AWG | 1/0 AWG | €889.58 | |
| THQB2170ST1 | 2 | 240V AC | 70A | - | - | 10 kAIC @ 120V | - | - | - | RFQ
|
| THQB2180 | 2 | 120/240V AC | 80A | Standard | Single | 10 kAIC @ 240V | 6 AWG | 1/0 AWG | €551.92 |
