EATON 5685D48G84 Complete Mining Molded Case Circuit Breaker, 1000 VAC, 600 A | BJ6TFD

EATON 5685D48G84 Molded Case Circuit Breaker, Hmam Type, 1500-3000A Trip Rating, 3-Pole, 600A, 1000 V

Item: BJ6TFDModel: 5685D48G84
Check Availability
In Stock
Amperage Rating

Get it by Tuesday, Dec 23

€46,823.18 /unit
Add To Cart
Request a Quote

Payment

Delivery

Product Specifications:

Item Circuit Breaker
Amperage Rating 600A
Circuit Breaker Type HMAM
Class Mining
Height 5 1/2"
Interrupt Rating 18 kAIC at 1000V AC
Length 5 1/2"
Magnetic Trip Range 1500-3000A
Number Of Poles 3
Product Datasheet eaton-5685d48g84.pdf
Trip Rating 1500-3000A
Trip Type Fixed Thermal, Fixed Magnetic
Voltage 1000V AC
Warranty Eaton Selling Policy 25-000, One (1) Year From The Date Of Installation Of The Product Or Eighteen (18) Months From The Date Of Shipment Of The Product, Whichever Occurs First.
Width 5 1/2"

Shipping Info:

Ship weight (kg) 3.02
Ship height (cm)13.97
Ship length (cm)13.97
Ship width (cm)13.97
Country of OriginUS

Documentation:

Datasheet

Product Variants

ProductModelNumber Of PolesCircuit Breaker TypeVoltageTypeFrame SizePrice
EATON 1230C83G06 Molded Case Circuit Breaker, 500 VAC, 400 A, 150 kA Interrupt, 3 Poles, Magnetic Trip | BJ6AXW 1230C83G063AQB-L400QM500VAccessories And TerminalsFrame J-K€75,781.59
RFQ
EATON 1230C83G05 Molded Case Circuit Breaker, 500 VAC, 400 A, 100 kA Interrupt, 3 Poles, Magnetic Trip | BJ6AYE 1230C83G053AQB-LL400QS500VAccessories And TerminalsFrame J-K€75,781.59
RFQ
EATON 1241C32G01 Molded Case Circuit Breaker, 500 VAC, 100 kA Interrupt, 3 Poles | BJ6AYN 1241C32G013AQB-LL400QS500V AC--€74,158.05
EATON 1241C32G04 Molded Case Circuit Breaker, 500 VAC, 100 kA Interrupt, 3 Poles | BJ6AYX 1241C32G043AQB-LL400QS500V AC--€74,158.05
EATON 1241C33G04 Molded Case Circuit Breaker, 500 VAC, 100 kA Interrupt, 3 Poles | BJ6AZD 1241C33G043AQB-LL400QS500V AC--€83,345.43
EATON 1241C32G02 Molded Case Circuit Breaker, 500 VAC, 200 A, 150 kA Interrupt, 3 Poles | BJ6AZE 1241C32G023AQB-LL400QS500V AC--€74,158.05
EATON 1241C34G38 Molded Case Circuit Breaker, 500 VAC, 150 kA Interrupt, 3 Poles | BJ6AZR 1241C34G383AQB-LL400QS500V AC--€83,345.43
