DAYTON 24EP28 Timer Relay 180 Second 8 Pin 10a Dpdt 12v
Item: AF8ARFModel: 24EP28
7 In Stock
Ships within 2 days via
10.00% off
€83.44 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Time Delay Relay |
| Adjustment Method | Potentiometer |
| Amps Rating | 10A |
| Base Shape | Octal |
| Base Type | Octal |
| Base Type - Plug In Relay | Octal |
| Body Depth | 1.7" |
| Body Height | 2.9" |
| Body Width | 2 2/5" |
| Coil Rating | 2W |
| Coil Rating | 2 W |
| Coil Volts | 12V DC |
| Compatible With Grainger Part Number | 1EGP3, 1EGP5, 5X852 |
| Contact Amp Rating | 10A |
| Contact Form | DPDT |
| Contact Material | Silver Nickel |
| Contact Rating (ac) | 10A @ 240V |
| Contact Rating (dc) | 10A @ 30V |
| Current Rating | 10A |
| Delay Function | Cycle On |
| Electrical Connection | Socket |
| Electrical Connection Type | Pin |
| Electrical Operating Durability | 100000 |
| Environmental Protection | Enclosed |
| Flat Pin Width | Not Applicable |
| Frequency | 50/60 Hz |
| Function | Repeat Cycle (On First) |
| Input Voltage | 12V DC |
| Ip Rating | IP20 |
| Max. Time Setting | 3 min. |
| Max. Time Setting - Timer | 3 min. |
| Maximum Operating Temperature | 122°F |
| Mechanical Operating Durability | 10000000 |
| Min. Time Setting | 1.8 sec. |
| Min. Time Setting - Timer | 1.8 sec. |
| Minimum Operating Temperature | -18°F |
| Minimum Time Setting | 1.8 sec. |
| Mounting | Plug In |
| Mounting - Relay | Plug In |
| No. Of Pins | 8 |
| No. Of Pins - Relay | 8 |
| Number Of Delay Functions | 1 |
| Number Of Pins | 8 |
| Number Of Pins/terminals | 8 |
| Operating Functions | 7 |
| Operating Time Accuracy | +0% -50% (Minimum Setting (Adjustable)), +2% 50Ms (Fixed), +5% -0% (Maximum Setting (Adjustable)) |
| Overall Depth | 3.1" |
| Overall Height | 3.1" |
| Pins | 8 |
| Power Consumption | 2 VA |
| Relay Mounting Style | Socket |
| Reset Method | Time Limit Reset |
| Resistive Contact Amp Rating | 10A |
| Sealing | Enclosed |
| Socket Code | A |
| Status Indicator | No |
| Status Indicator | None |
| Timing Relay Functionality | Repeat Cycle |
Shipping Info:
| Ship weight (kg) | 0.11 |
| Ship height (cm) | 4.78 |
| Ship length (cm) | 10.8 |
| Ship width (cm) | 6.35 |
| HS code | 8536490075 |
| Country of Origin | US |
Product Variants
| Product | Model | Number Of Pins | Socket Code | Amps Rating | Min. Time Setting | Environmental Protection | Delay Function | Max. Time Setting | Pins | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
1EJL6 | 8 | K | 5A | 0.1 sec. | Sealed | - | - | 8 | €97.52 | |
 |
5DPZ7 | 8 | A | 10A | 0.05 sec. | Enclosed | On Delay | - | 8 | €141.41 | |
 |
24EN65 | 8 | A | 10A | 0.1 sec. | Enclosed | Interval On | 10 sec. | 8 | €71.21 | |
|
24EN66 | 8 | A | 10A | 0.6 sec. | Enclosed | Interval On | 60 sec. | 8 | €70.70 | |
|
24EN67 | 8 | A | 10A | 1.8 sec. | Enclosed | Interval On | 3 min. | 8 | €70.70 | |
|
24EN68 | 8 | A | 10A | 3 sec. | Enclosed | Interval On | 5 min. | 8 | €71.90 | |
|
24EN80 | 11 | B | 10A | 0.1 sec. | Enclosed | Off Delay | 10 sec. | 11 | €136.35 |
