DAYTON 20CK16 Sleeved Fire Damper Static Vertical
Item: AG9GMUModel: 20CK16
7 In Stock
0.6 sq. ft.
Ships within 2 days via
10.00% off
€147.46 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Fire Damper with Sleeve |
| Airflow Direction | Horizontal, Vertical |
| Application | Fire |
| Blade Material | Galvanized Steel |
| Blade Type | Curtain |
| Closure Type | Gravity |
| Damper Application | Fire |
| Damper Depth | 3 11/16" |
| Damper Height | 11 3/4" |
| Damper Height | 11-3/4" |
| Damper Item | Sleeved Fire Damper |
| Damper Shape | Square |
| Damper Type | Static |
| Damper Width | 11-3/4" |
| Damper Width | 11 3/4" |
| Finish | Galvanized |
| Fire Rating | 1.5 hrs. |
| For Duct Shape | Square |
| Frame Depth | 12" |
| Frame Less Flange | 144 sq. in. |
| Frame Material | Galvanized Steel |
| Frame Material Thickness | 22 ga. |
| Free Area | 0.6 sq. ft. |
| Fusible Link Temperature | 165°F |
| Includes | Ul Fusible Link |
| Material | Steel |
| Material Thickness | 22 ga. |
| Maximum Ambient Temperature | 165°F |
| Mounting Location | Wall |
| Mounting Position | Horizontal, Vertical |
| Mounting Style | Static, Vertical |
| Mounting Type | Static Vertical |
| Nominal Duct Height | 12" |
| Nominal Duct Width | 12" |
| Overall Height | 11 3/4" |
| Overall Length | 12" |
| Overall Width | 11 3/4" |
| Recommended Retaining Angle | 2TGH2 |
| Rough Opening Shape | Square |
| Rough Opening Width | 12" |
| Shape | Square |
| Switch Action | Normally Open |
Shipping Info:
| Ship weight (kg) | 4.34 |
| Ship height (cm) | 29.85 |
| Ship length (cm) | 30.48 |
| Ship width (cm) | 29.85 |
| Country of Origin | US |
Product Details:
- Damper Depth : 3-11/16"
- Fusible Link : 165 Degrees F
Product Variants
| Model | Damper Type | Closure Type | For Duct Shape | Overall Length | Mounting Position | Fusible Link Temperature | Price | |
|---|---|---|---|---|---|---|---|---|
| 20CK13 | Static | Gravity | Square | 12" | Horizontal, Vertical | 165°F | €151.26 | |
| 20CK14 | Static | Gravity | Square | 12" | Horizontal, Vertical | 165°F | €137.78 | |
| 20CK15 | Static | Gravity | Square | 12" | Horizontal, Vertical | 165°F | €153.35 | |
| 20CK17 | Dynamic | Spring | Square | 12" | - | - | €164.68 | |
| 20CK18 | Dynamic | Spring | Square | 12" | - | - | €171.27 | |
| 20CK19 | Dynamic | Spring | Square | 12" | - | - | €178.46 | |
| 20CK20 | Dynamic | Spring | Square | 12" | Horizontal, Vertical | 165°F | €191.18 |
