DAYTON 026-756-1205 AC Gearmotor, Right Angle, Single Output Shaft, Keyed, PSC, TEFC, 330 RPM, 0.25 hp Input
Get it by Wednesday, Dec 24
€ 24,99 Flat Shipping + VAT € 24,99 flat shipping is applicable on orders with an aggregate weight less than 10kg. Orders exceeding 10kg will be charged default shipping rates.
10.00% off
€1,108.53 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | AC Gearmotor |
| Agma Gear Class | Not Applicable |
| Amps | 2.4/1.3A |
| Application | Not Applicable |
| Base To Center Of Shaft | 1 17/25" |
| Bearing Type | Not Applicable |
| Brake Type | None |
| Capacitor Required | Yes (20 µF, 370V) |
| Color | Black |
| Direction Of Output | Left Hand |
| Duty Rating | Continuous |
| Efficiency | Not Applicable |
| Enclosure Type | Totally Enclosed Fan Cooled |
| External Hardware Material | Not Applicable |
| Features | Not Applicable |
| For Location | Not Applicable |
| Frequency | 50/60 Hz |
| Full Load Amps | 2.4/1.3A |
| Gear Material | Not Applicable |
| Gear Ratio | 5:1 |
| Gear Type | Not Applicable |
| Housing Material | Not Applicable |
| Housing Material Finish | Not Applicable |
| Housing Mount Hole Size | Not Applicable |
| Includes | Not Applicable |
| Includes Capacitor | Yes |
| Includes Junction/conduit Box | Yes |
| Input Hp | 1/4 hp |
| Inverter Rated | No |
| Inverter Rating | Not Applicable |
| Ip Rating | Not Applicable |
| Keyway Depth | Not Applicable |
| Keyway Length | Not Applicable |
| Keyway Type | Square |
| Keyway Width | 3/16" |
| Length Less Shaft | Not Applicable |
| Lubrication | Not Applicable |
| Max. Ambient Temp. | 104°F |
| Max. Torque | 15 lbs.-in. |
| Maximum Output Speed | Not Applicable |
| Maximum Torque | 15 lbs.-in. |
| Min. Ambient Temp. | Not Applicable |
| Motor Duty Class | Continuous |
| Motor Enclosure | Totally Enclosed Fan Cooled |
| Motor Frame Designation | Not Applicable |
| Motor Insulation Class | Not Applicable |
| Motor Type | Permanent Split Capacitor |
| Mount Hole Center-to-center Length | Not Applicable |
| Mount Hole Center-to-center Width | Not Applicable |
| Mounting Orientation | Any Angle |
| Mounting Type | Not Applicable |
| Nameplate Rpm | 330 RPM |
| Nameplate Rpm Range | 251-500 RPM |
| Number Of Output Shafts | 1 |
| Number Of Stages | 1 |
| Operating Voltage | 115/230V AC |
| Output Connection Depth | Not Applicable |
| Output Face Bolt Circle Diameter | Not Applicable |
| Output Location | Left Hand |
| Output Shaft Dia. | Not Applicable |
| Output Shaft Length | Not Applicable |
| Output Shaft Type | Keyed |
| Overall Height | Not Applicable |
| Overall Length | Not Applicable |
| Overall Width | Not Applicable |
| Overhung Load Capacity | 270 lbs.-ft. |
| Phase | Not Applicable |
| Resistance Properties | Not Applicable |
| Rotation | CW/CCW |
| Seal Material | Not Applicable |
| Seal Type | Not Applicable |
| Shaft Material | Not Applicable |
| Shaft Orientation | Right Angle |
| Starting Torque | Not Applicable |
| Thermal Protection | No |
| Type | Permanent Split Capacitor |
| Vent Type | Not Applicable |
| Voltage | 115/230V AC |
| Width Less Shaft | Not Applicable |
Shipping Info:
| Ship weight (kg) | 8.55 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 2.54 |
| Ship width (cm) | 2.54 |
| Country of Origin | US |
Product Variants
| Product | Model | Motor Type | Overhung Load Capacity | Base To Center Of Shaft | Operating Voltage | Gear Ratio | Lubrication | Gear Material | Bearing Type | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
4CVZ4 | Capacitor-Start | 980 lbs.-ft. | 3 1/4" | 115/208-230V AC | 391 | Gear Oil | Forged Bronze, Hardened Steel | Ball | €2,564.39 | |
 |
4CUK7 | Capacitor-Start | 1530 lbs.-ft. | 2 1/2" | 115/208-230V AC | 181 | Oil Filled | Hardened Steel, Forged Bronze | Ball On Motor, Roller On Case | €2,202.26 | |
|
4CVZ3 | Capacitor-Start | 980 lbs.-ft. | 3 1/4" | 115/208-230V AC | 581 | Gear Oil | Forged Bronze, Hardened Steel | Ball | €2,484.67 | |
 |
4CVU3 | Capacitor-Start | 670 lbs.-ft. | 2 1/2" | 115/208-230V AC | 391 | Gear Oil | Forged Bronze, Hardened Steel | Ball | €2,176.09 | |
|
4CVT9 | Capacitor-Start | 670 lbs.-ft. | 2 1/2" | 115/208-230V AC | 581 | Gear Oil | Forged Bronze, Hardened Steel | Ball | €2,376.31 | |
|
4CVU5 | Capacitor-Start | 670 lbs.-ft. | 2 1/2" | 115/208-230V AC | 181 | Gear Oil | Forged Bronze, Hardened Steel | Ball | €2,112.42 | |
|
4CVU1 | Capacitor-Start | 670 lbs.-ft. | 2 1/2" | 115/208-230V AC | 391 | Gear Oil | Forged Bronze, Hardened Steel | Ball | €2,150.00 |
