CLEVELAND C55090 1002 Three Piece Tap Kit
Item: CQ9MTMModel: C55090Cross Ref: 435P79 / 1002
7 In Stock
Ships within 2 days via
10.00% off
€414.32 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Tap Kit |
| Coolant Fed | Non Coolant Through |
| Extended Shank | No |
| Features | Plug |
| Finish | Bright |
| Fits Class | Class 3B |
| Includes | (1) 1/2"-13 Nc, (1) 1/2"-20 Nf, (1) 1/4"-20 Nc, (1) 1/4"-28 Nf, (1) 3/8"-16 Nc, (1) 3/8"-24 Nf, (1) 5/16"-18 Nc, (1) 5/16"-24 Nf, (1) 7/16"-14 Nc, (1) 7/16"-20 Nf |
| List Number | 1002 |
| Measurement System | Fractional Inch |
| No. Of Pieces | 10 |
| Number Of Flutes | 4 |
| Number Of Taps | 3 |
| Overall Length | 2 1/2", 2 23/32", 2 15/16", 3 5/32", 3 3/8" |
| Primary Material Application | Aluminum, Brass, Bronze, Cast Iron, Copper, Stainless Steel, Steel |
| Primary Material Application Iso Code | K, M, N, P |
| Shank Dia. | 1/4", 23/64", 3/8", 5/16" |
| Shank Length | Various |
| Square Size | Various |
| Standards | Uscti Table 302A |
| System Of Measurement | Imperial |
| Tap Chamfer | Plug |
| Tap Finish | Bright |
| Tap Material | High Speed Steel |
| Tap Shank Standard | USCTI Table 302A |
| Tap Style | Straight Flute (Hand) |
| Tap Thread Size | 1/4"-20, 1/4"-28, 5/16"-18, 5/16"-24, 3/8"-16, 3/8"-24, 7/16"-14, 7/16"-20, 1/2"-13, 1/2"-20 , 1/4"-20, 1/4"-28, 5/16"-18, 5/16"-24, 3/8"-16, 3/8"-24, 7/16"-14, 7/16"-20, 1/2"-13, 1/2"-21 , 1/4"-20, 1/4"-28, 5/16"-18, 5/16"-24, 3/8"-16, 3/8"-24, 7/16"-14, 7/16"-20, 1/2"-13, 1/2"-22 , 1/4"-20, 1/4"-28, 5/16"-18, 5/16"-24, 3/8"-16, 3/8"-24, 7/16"-14, 7/16"-20, 1/2"-13, 1/2"-23 , 1/4"-20, 1/4"-28, 5/16"-18, 5/16"-24, 3/8"-16, 3/8"-24, 7/16"-14, 7/16"-20, 1/2"-13, 1/2"-24 , 1/4"-20, 1/4"-28, 5/16"-18, 5/16"-24, 3/8"-16, 3/8"-24, 7/16"-14, 7/16"-20, 1/2"-13, 1/2"-25 , 1/4"-20, 1/4"-28, 5/16"-18, 5/16"-24, 3/8"-16, 3/8"-24, 7/16"-14, 7/16"-20, 1/2"-13, 1/2"-26 , 1/4"-20, 1/4"-28, 5/16"-18, 5/16"-24, 3/8"-16, 3/8"-24, 7/16"-14, 7/16"-20, 1/2"-13, 1/2"-27 , 1/4"-20, 1/4"-28, 5/16"-18, 5/16"-24, 3/8"-16, 3/8"-24, 7/16"-14, 7/16"-20, 1/2"-13, 1/2"-28 , 1/4"-20, 1/4"-28, 5/16"-18, 5/16"-24, 3/8"-16, 3/8"-24, 7/16"-14, 7/16"-20, 1/2"-13, 1/2"-29 |
| Tap Type | Straight Flute |
| Thread Direction | Right Hand |
| Thread Length | 1, 1 1/8", 1 1/4", 1 7/16" |
| Thread Limit | 2B |
| Thread Size | 1/4"-20, 1/4"-28, 5/16"-18, 5/16"-24, 3/8"-16, 3/8"-24, 7/16"-14, 7/16"-20, 1/2"-13, 1/2"-20 |
| Thread Standard | UNC, UNF |
| Threads Per Inch | 13, 14, 16, 18, 20, 24, 28 |
Shipping Info:
| Ship weight (kg) | 0.51 |
| Ship height (cm) | 8.89 |
| Ship length (cm) | 15.01 |
| Ship width (cm) | 3.35 |
| Country of Origin | US |
Product Variants
| Model | Overall Length | Number Of Flutes | Thread Size | Thread Length | 75% Thread Drill Size | Tap Chamfer | Shank Dia. | Thread Standard | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| C54235 | 2" | 3 | - | 3/8" | #33 | Bottom, Plug, Taper | 9/64" | Fine | €55.65 | |
| C54324 | 2 3/8" | 4 | #10-24 | 1/2" | #25 | Bottom, Plug, Taper | 3/16" | Coarse | €57.11 | |
| C54332 | 2 3/8" | 4 | #10-24 | 1/2" | #25 | Bottom, Plug, Taper | 3/16" | Coarse | €55.65 | |
| C54359 | 2 3/8" | 4 | #10-32 | - | #21 | Bottom, Plug, Taper | 3/16" | Fine | €55.65 | |
| C54351 | 2 3/8" | 4 | #10-32 | 1/2" | #21 | Bottom, Plug, Taper | 3/16" | Fine | €62.20 | |
| C54388 | 2 3/8" | 4 | #12-24 | 1/2" | 4.45 mm | Bottom, Plug, Taper | 7/32" | Coarse | €58.62 | |
| C54392 | 2 3/8" | 4 | #12-28 | 1/2" | 4.6 mm | Bottom, Plug, Taper | 7/32" | Fine | €64.12 |
