BURNDY YS28 Short Barrel Splice, 3.57 Inch Size, 0.69 Inch Outer Diameter, Copper
Item: CF4AVKModel: YS28Cross Ref: 454H11
7 In Stock
91 mm
4/0 AWG
Ships within 2 days via
10.00% off
€25.17 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Short Barrel Splice |
| Barrel Finish | Tin Plated |
| Barrel Outside Diameter | 0.69" |
| Barrel Size | Long |
| Color Code | Purple |
| Compatible Installation Tool Model Number | MD6, MD7-34R, OUR840, PAT81KFT-18V, Y35, Y39, Y46, Y750, Y81KFT, Y81KFTMBH |
| Contact Finish | Tin |
| Contact Material | Copper |
| Die Code | 15 |
| For Conductor Material | Copper |
| For Wire Type | Stranded |
| Length | 3.57" |
| Material | Copper |
| Maximum Conductors | 2 |
| Maximum Operating Temperature | 194°F |
| Maximum Voltage | 35 kV |
| Maximum Wire Insulation Diameter | 0.69" |
| Maximum Wire Size | 4/0 AWG |
| Minimum Wire Size | 4/0 AWG |
| Number Of Crimps | 2 |
| Outside Dia. | 0.69" |
| Overall Length | 3.57" |
| Rohs Compliant | Yes |
| Seam Style | Seamless |
| Special Features | Center Conductor Stops, High Pull Out Force, Oil Stop: No, Tapered End: No |
| Strip Length | 1-11/16" |
| Strip Length | 1 11/16" |
| Termination Type | Crimp |
| Voltage Rating | 8/25" |
Shipping Info:
| Ship weight (kg) | 0.1 |
| Ship height (cm) | 1.75 |
| Ship length (cm) | 9.07 |
| Ship width (cm) | 1.75 |
| Country of Origin | US |
