BROWNING VFBB-220 764441 Ball Bearing Unit, 3-3/4 in OAL/Dia, 1-1/4 in Bore Dia, 3-Bolt
Get it by Tuesday, Aug 18
€226.27 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Ball Bearing |
| Bearing Type | Three Bolt Flange Bracket |
| Bore Dia. | 1 1/4" |
| Duty Type | Standard Duty |
| Family Series | Browning Bearings |
| Housing Material | Cast Iron |
| Housing Width | 3 3/4" |
| Insert Material | Steel, Black Oxide |
| Insert Material | 52100 Steel, Black Oxide |
| Locking Device | Boa Concentric |
| Max. Operating Temp. | 200°F |
| Max. Speed | 4000 RPM |
| Operating Temp. Range | -20°F to +200°F |
| Overall Width | 3 3/4" |
| Replacement Bearing | VB-220 |
| Seal Type | Single Lip Contact Seal With Flinger |
| Shaft Dia. | 1 1/4" |
| Static Radial Load Capacity | 3493 lbf. |
| Type Of Bearing | Ball |
Shipping Info:
| Ship weight (kg) | 1.4 |
| Ship height (cm) | 17.3 |
| Ship length (cm) | 11.13 |
| Ship width (cm) | 5.23 |
| Country of Origin | MX |
Product Variants
| Product | Model | Bore Dia. | Insert Material | Static Radial Load Capacity | Bearing Type | Overall Width | Housing Width | Shaft Dia. | Bolt Center To Center Length | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
VFBB-216 | - | 52100 Steel | 1651 lbf. | Flange Bracket | 2 3/4" | 2 3/4" | - | - | €162.28 | |
 |
VFBB-232S | - | 52100 Steel | 5216 lbf. | Flange Bracket | - | - | - | - | €308.90 | |
 |
VFBB-215 | - | 52100 Steel, Black Oxide | 1651 lbf. | Three Bolt Flange Bracket | 2 3/4" | 2 3/4" | 0.938" | 1 5/8" | €162.28 | |
|
VFBB-220S | 1 1/4" | 52100 Steel | 2567 lbf. | Flange Bracket | 3.2188" | 3.22" | 1 1/4" | 1 7/8" | €192.06 | |
|
VFBB-231 | 1 15/16" | 52100 Steel | 5216 lbf. | Flange Bracket | - | - | 1 15/16" | - | €308.90 | |
|
VFBB-218 | 1 1/8" | 52100 Steel | 2567 lbf. | Flange Bracket | 3.2188" | 3.22" | 1 1/8" | 1 7/8" | €192.06 |
