BROWNING VF4B-231 766238 Ball Bearing Unit, 5-5/8 in OAL/Dia, 1-15/16 in Bore Dia, 4-Bolt, 3000 rpm Max Speed, Non-Expansion Normal Duty Round/Straight Bore
Get it by Tuesday, Aug 18
€225.44 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Ball Bearing |
| Bearing Design | Non Expansion |
| Bearing Insert Coating | Black Oxide Coated Inner Ring |
| Bearing Type | Four Bolt Flange |
| Bolt Center To Center Length | 4 3/8" |
| Bolt Size | 14/25" |
| Bore Dia. | 1 15/16" |
| Bore Size - Inch | 1.938" |
| Centerline To Front Face | 1.344" |
| Duty Series | Normal |
| Duty Type | Standard Duty |
| Dynamic Radial Load Capacity | 7889 lbs. |
| Expansion | No |
| Family Series | Browning Bearings |
| Flange Type | 4 Bolt Flange |
| Foot Height | 5/8" |
| Housing Base | Semi Solid |
| Housing Construction | One Piece |
| Housing Material | Cast Iron |
| Housing Width | 5 5/8" |
| Insert Material | 52100 Bearing Steel, Black Oxided Inner |
| Insert Material | Bearing Steel, Black Oxided Inner |
| Inside Dia. | 1.94" |
| Length Through Bore | 2.09" |
| Locking Device | Boa Concentric |
| Max. Speed | 3000 RPM |
| Misalignment Type | Static Only |
| Operating Temp. Range | -20°F to +200°F |
| Outer Ring Land Profile | Standard |
| Pilot Configuration | No Pilot |
| Retainer Type | Ball Riding Retainer |
| Seal Type | Single Lip Contact Seal With Flinger |
| Static Radial Load Capacity | 5216 lbs. |
| Type Of Bearing | Ball |
Shipping Info:
| Ship weight (kg) | 2.79 |
| Ship height (cm) | 6.2 |
| Ship length (cm) | 17.15 |
| Ship width (cm) | 16.51 |
| Country of Origin | MX |
Product Variants
| Product | Model | Bore Dia. | Static Radial Load Capacity | Duty Type | Overall Height | Bolt Center To Center Length | Shaft Dia. | Length Through Bore | Dynamic Radial Load Capacity | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
VF4B-223 | 1 7/16" | 3493 lbs. | Standard Duty | - | - | - | 1 3/4" | 5782 lbs. | €165.19 | |
 |
VF4B-235 | 2 3/16" | 6601 lbf. | Standard Duty | 2 3/8" | 5 1/8" | 2 3/16" | - | - | €278.74 | |
|
VF4B-224 | - | 4467 lbf. | Standard Duty | 5 1/8" | - | 1 1/2" | 2" | - | €177.67 | |
 |
VF4B-332 | - | 5216 lbf. | Medium Duty | 2 3/8" | 5 1/8" | - | - | - | €292.62 | |
|
VF4B-222 | 1 3/8" | 3493 lbf. | Standard Duty | 1.813" | 3.625" | 1 3/8" | - | - | €170.14 | |
|
VF4B-232 | - | 6601 lbs. | Standard Duty | - | 5 1/8" | - | 2.094" | 9752 lbs. | €278.74 | |
|
VF4B-220 | 1 1/4" | 3493 lbf. | Standard Duty | 1.813" | 3.625" | 1 1/4" | - | 5782 lbf. | €165.19 |
