BROWNING VF2S-324 766220 Ball Bearing Unit, 1-1/2 Inch Bore, 2-Bolt Flange Mount, Set Screw Locking
Get it by Monday, Aug 17
€184.73 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Ball Bearing |
| Bearing Type | Two Bolt Flange |
| Bolt Center To Center Length | 5.844" |
| Bore Dia. | 1 1/2" |
| Duty Type | Medium Duty |
| Dynamic Radial Load Capacity | 7901 lbf. |
| Family Series | Browning Bearings |
| Housing Material | Cast Iron |
| Housing Width | 1.3281" |
| Insert Material | Steel |
| Insert Material | 52100 Steel |
| Locking Device | Set Screw |
| Max. Operating Temp. | 200°F |
| Max. Speed | 3000 RPM |
| Operating Temp. Range | -20°F to +200°F |
| Overall Height | 2.0469" |
| Product Type | Flange-Mount Ball Bearing Units |
| Replacement Bearing | VS-324 |
| Seal Type | Single Lip Contact Seal With Flinger |
| Shaft Dia. | 1 1/2" |
| Static Radial Load Capacity | 5139 lbf. |
| Type Of Bearing | Ball |
Shipping Info:
| Ship weight (kg) | 2.07 |
| Ship height (cm) | 13.97 |
| Ship length (cm) | 13.97 |
| Ship width (cm) | 5.41 |
| Country of Origin | MX |
Product Variants
| Product | Model | Bore Dia. | Static Radial Load Capacity | Housing Width | Dynamic Radial Load Capacity | Bolt Center To Center Length | Inside Ring Outside Dia. | Bolt Size | Foot Height | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
VF2S-224 | 1 1/2" | 4467 lbs. | 1.3" | 7340 lbs. | 5.656" | 2.063" | 1/2" | 5/8" | €141.83 | |
 |
VF2S-116 | - | 1651 lbs. | 0.9531" | 2801 lbs. | 3.891" | 1 3/8" | 7/16" | 1/2" | €68.23 | |
 |
VF2S-223 | 1 7/16" | 3493 lbs. | 1.1563" | 5782 lbs. | 5 1/8" | 1.859" | 1/2" | 0.594" | €124.01 | |
 |
VF2S-220 | 1 1/4" | 3493 lbs. | 1.1563" | 5782 lbs. | 5 1/8" | 1.859" | 1/2" | 0.594" | €124.01 | |
 |
VF2S-235 | - | 6601 lbs. | 1.5156" | 9752 lbs. | 7 1/4" | 2.719" | 5/8" | 0.813" | €229.34 | |
|
VF2S-323 | 1 7/16" | 4467 lbf. | 1.2969" | - | 5.656" | - | - | - | €155.57 | |
 |
VF2S-227 | - | 5139 lbs. | 1.33" | 7901 lbs. | 5.844" | 2.297" | 9/16" | 5/8" | €163.37 |
