BROWNING 3694221 3B5V58 V-Belt Sheave, Multiple, Bushed Bore, 3 Groove, Cast Iron
Item: BA2EDLModel: 3694221Cross Ref: 3B5V58
7 In Stock
6 2/25"
Ships within 2 days via
€236.84 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | V-Belt Sheave |
| Belt Series | A, B, 5V Series |
| Bore Dia. | 1/2" to 1 15/16" |
| Bore Type | Split Taper |
| Bushing Bore Range | 1/2" to 2 7/16" |
| Bushing Type | B |
| Face Width | 2 7/16" |
| Hub Projection | 17/64" |
| Keyway | Yes |
| Material | Cast Iron |
| Max. Pitch Dia. | 5.9" |
| Min. Pitch Dia. | 5 2/5" |
| Min. Plain Bore | No |
| No. Of Grooves | 3 |
| Outside Dia. | 6 2/25" |
| Overall Length | 2 29/32" |
| Pitch Dia. (5v) | 5.9" |
| Pitch Dia. (a) | 5 3/5" |
| Pitch Dia. (b) | 6.1" |
| Series | B5V Series |
| Suitable For Use With | Gripbelt A And B, 5V Cross Section Belts |
| System Of Measurement | Imperial |
| Type | Type 3 |
| Weight | 3.967 Kg |
Shipping Info:
| Ship weight (kg) | 3.85 |
| Ship height (cm) | 15.44 |
| Ship length (cm) | 7.39 |
| Ship width (cm) | 15.44 |
| Country of Origin | US |
Product Variants
| Product | Model | Outside Dia. | Bore Dia. | Overall Length | Type | Bore Type | Material | Face Width | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
 |
3694338 | 9 17/25" | 1/2" to 1 15/16" | 2 29/32" | Arm Type 4 | Split Taper | Cast Iron | 2 7/16" | €315.03 | |
 |
3694346 | 11 7/25" | 1/2" to 1 15/16" | 2 29/32" | Arm Type 4 | Split Taper | Cast Iron | 2 7/16" | €368.17 | |
 |
3694379 | 15 17/25" | 1/2" to 2 7/16" | 2 27/32" | Type 4 Arm | Split Taper | Cast Iron | 2 7/16" | €570.15 | |
 |
3694288 | 7 7/25" | 1/2" to 1 15/16" | 2 29/32" | Type 4 Web | Split Taper | Cast Iron | 2 7/16" | €256.57 | |
 |
3694304 | 8 7/25" | 1/2" to 1 15/16" | 2 29/32" | Arm Type 4 | Split Taper | Cast Iron | 2 7/16" | €272.52 | |
 |
3694239 | 6 7/25" | 1/2" to 1 15/16" | 2 29/32" | Type 3 | Split Taper | Cast Iron | 2 7/16" | €243.06 | |
 |
3694163 | 4 22/25" | 1/2" to 1 15/16" | 3 1/2" | Type 5 | Split Taper | Cast Iron | 2 7/16" | €212.11 |
