BROWNING 2760387 2AK64X25MM V-Belt Sheave, Finish Bore, 2 Groove, Cast Iron, 6 1/4 in OD, 25 mm Bore Dia
Item: BA3BBBModel: 2760387Cross Ref: 2AK64X25MM
7 In Stock
6 1/4"
25 mm
Ships within 2 days via
€271.34 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | V-Belt Sheave |
| Belt Series | 3L, 4L, A Series |
| Bore Dia. | 25 mm |
| Bore Type | Finished |
| Bushing Type | No Bushing |
| Keyway | Yes |
| Material | Cast Iron |
| Max. Belt Width | 1/2" |
| Max. Pitch Dia. | 6" |
| Min. Belt Width | 3/8" |
| Min. Pitch Dia. | 5.66" |
| Min. Plain Bore | No |
| No. Of Grooves | 2 |
| Outside Dia. | 6 1/4" |
| Pitch Dia. (a) | 6" |
| Pitch Dia. (b) | 6 2/5" |
| Series | AK Series |
| Suitable For Use With | AB Cross Section V-Belts |
| System Of Measurement | Metric |
| Type | Type 3 |
Shipping Info:
| Ship weight (kg) | 2.16 |
| Ship height (cm) | 15.88 |
| Ship length (cm) | 2.54 |
| Ship width (cm) | 15.88 |
| Country of Origin | US |
Product Variants
| Product | Model | Bore Type | Outside Dia. | Bore Dia. | Overall Length | Type | Material | Face Width | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
 |
3195377 | Finished | 4 3/4" | 1 3/8" | 1 27/32" | Type 2 | Cast Iron | 1 3/8" | €368.18 | |
 |
3195435 | Finished | 5.45" | 1 3/8" | 1 27/32" | Type 3 | Cast Iron | 1 3/8" | €378.61 | |
 |
3195500 | Finished | 6 1/4" | 1 3/8" | 1 23/32" | Type 3 | Cast Iron | 1 3/8" | €308.21 | |
 |
3195567 | Finished | 11 1/4" | 1 3/8" | 1 23/32" | Type 1 | Cast Iron | 1 3/8" | €778.68 | |
 |
1042845 | Split Taper | 6 1/4" | 3/8" to 1 1/2" | 1 13/32" | Type 3 | Cast Iron | 1 3/8" | €180.82 | |
 |
1042944 | Split Taper | 18 1/4" | 3/8" to 1 1/2" | 1 13/32" | Type 3 | Cast Iron | 1 3/8" | €571.03 | |
 |
3195393 | Finished | 4.95" | 1 3/8" | 1 27/32" | Type 2 | Cast Iron | 1 3/8" | €490.97 |
