ATLAS COPCO 8411415018 PZB15-L-AR500-20 Piston Air Motor, 0.16 hp Max output, 300 rpm Max Speed, 2.8 ft-lb Max Torque
Get it by Tuesday, Dec 23
€1,875.00 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Piston Air Motor |
| Air Consumption At Max Output | 9.2 CFM |
| Atex | Yes |
| Atex Code Dust | EX II 2 D EX H IIIC T85°C DB |
| Atex Code Gas | EX II 2 G EX H IIC T6 GB |
| Atex Max Temperature | 85°C |
| External Parts Finish | Hardened |
| External Parts Material | Aluminum, Steel |
| Ingress Protection Rating | IP65 |
| Inlet Hose Size | 1/4" |
| Max Ambient Temperature | 40°C |
| Max Output | 16/100 hp |
| Max Working Pressure | 100 psig |
| Maximum Allowed Speed | 500 RPM |
| Min Starting Torque | 5.9 lbs.-ft. |
| Outlet Hose Size | 1/4" |
| Product Datasheet | atlas-copco-8411415018.pdf |
| Rotation Direction | Reversible |
| Shaft Loading Code | A |
| Shaft Type | Keyed |
| Speed At Max Output | 300 RPM |
| Stall Torque | 5.9 lbs.-ft. |
| Torque At Max Output | 2.8 lbs.-ft. |
Shipping Info:
| Ship weight (kg) | 2.04 |
| Ship height (cm) | 22.5 |
| Ship length (cm) | 24.99 |
| Ship width (cm) | 16 |
| Country of Origin | HU |
Documentation:
Product Variants
| Product | Model | Stall Torque | Price | |
|---|---|---|---|---|
 |
8411415111 | 5.9 lbs.-ft. | €1,987.50 | |
 |
8411415129 | 5.9 lbs.-ft. | €2,071.87 | |
|
8411415000 | 5.9 lbs.-ft. | €1,875.00 | |
|
8411415026 | 5.9 lbs.-ft. | €1,875.00 | |
 |
8411415034 | 5.9 lbs.-ft. | €2,606.25 | |
|
8411415067 | 5.9 lbs.-ft. | €1,875.00 | |
 |
8411415091 | 5.9 lbs.-ft. | €2,090.62 |
