ARMSTRONG WORLD INDUSTRIES 15B6 Steam Trap, 1 1/2 Inch Size NPT Connections, 5 3/4 Inch Size End to End Length
Get it by Monday, Dec 22
€ 24,99 Flat Shipping + VAT € 24,99 flat shipping is applicable on orders with an aggregate weight less than 10kg. Orders exceeding 10kg will be charged default shipping rates.
10.00% off
€792.77 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Steam Trap |
| Air Vent Material | Bronze, Stainless Steel |
| Allowable Pressure - Maximum | 175 psi |
| Allowable Temperature - Maximum | 377°F |
| Application | Steam Mains |
| Body Material | Cast Iron |
| Body Material Grade | Cast Iron |
| Condensate Capacity | 3100 lbs./hr. |
| Configuration | C Pattern |
| Distance Between Inlet And Outlet Port | 4 3/16" |
| End To End Length | 5 3/4" |
| Float Material | Cast Iron |
| Fnpt Size | 1 1/2" |
| Includes Air Vent | Air Vent Included |
| Includes Strainer | Strainer Not Included |
| Installation Orientation | Horizontal |
| Manufacturer Series | B Series |
| Max. Operating Pressure | 15 psi |
| Maximum Capacity At Maximum Pressure Load | 3100 lbs./hr. @ 15 psi |
| Overall Depth | 7 7/16" |
| Overall Length | 5 3/4" |
| Overall Width | 8 7/16" |
| Pipe Configuration | Same Side |
| Port Connection Gender | Female |
| Port Connection Size | 1 1/2" |
| Port Connection Type | NPT |
| Port Types Included | Air Vent |
| Steam Trap Type | Float and Thermostatic |
| Trap Position | Horizontal |
| Type | Float And Thermostatic |
Shipping Info:
| Ship weight (kg) | 9.25 |
| Ship height (cm) | 18.89 |
| Ship length (cm) | 14.61 |
| Ship width (cm) | 21.43 |
| Country of Origin | US |
Product Variants
| Product | Model | Condensate Capacity | Max. Operating Pressure | Steam Trap Type | Body Material | Distance Between Inlet And Outlet Port | Type | Fnpt Size | End To End Length | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
B2311C-2 | - | - | - | - | - | - | - | - | €471.83 | |
|
B2311C-1 | - | - | - | - | - | - | - | - | €469.23 | |
 |
815-150-250 | 7000 lbs./hr. | 250 psi | Inverted Bucket | Cast Iron | 10 1/4" | Inverted Bucket | 1 1/2" | 10 1/4" | €1,997.14 | |
|
815-150-130 | 11000 lbs./hr. | 130 psi | Inverted Bucket | Cast Iron | 10 1/4" | Inverted Bucket | 1 1/2" | 10 1/4" | €1,997.14 | |
|
815-150-030 | 9900 lbs./hr. | 30 psi | Inverted Bucket | Cast Iron | 10 1/4" | Inverted Bucket | 1 1/2" | 10 1/4" | €1,997.14 | |
|
30B6 | 2000 lbs./hr. | 30 psi | Float and Thermostatic | Cast Iron | 4 3/16" | Float And Thermostatic | 1 1/2" | 5 3/4" | €1,152.83 | |
 |
75A6 | 3100 lbs./hr. | 75 psi | Float and Thermostatic | Cast Iron | 4 3/16" | Float And Thermostatic | 1 1/2" | 7.438" | €1,259.62 |
