APOLLO VALVES PWR7480352 Elbow, 2 Inch Size, 45 Degree Street
Get it by Monday, Aug 17
€201.44 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Elbow, 45 Degree |
| Bend Angle | 45° |
| Bend Radius | 2 14/25" |
| Capped | Yes |
| Color | Gray |
| Connection Type | Press x Tube End |
| Continuous Medium Temp. | -40°F to +275°F |
| Contour Code | DW |
| D1 | 2.37 |
| D2 | 2.37 |
| Dimensions | 4.53" x 5" x 2.91" |
| Eccentric | No |
| Finish | Zinc Nickel Plated |
| Flange Compression Class | PN 16 |
| Grade | Grade St 35 |
| High Tensile Strength | Yes |
| Intrastat Code | 73079980 |
| Length | 115 mm |
| Length Of Connection 1 | 3.31" |
| Length Of Connection 2 | 3.99" |
| Material | Steel |
| Max. Media Temp. | 275°F |
| Max. Operating Pressure Liquid | 232 psi |
| Min. Media Temp. | -40°F |
| Outside Pipe Dia. 1 | 2.37" |
| Outside Pipe Dia. 2 | 2.37" |
| Peak Media Temp. | 302°F |
| Product Datasheet | apollo-valves-pwr7480352.pdf |
| Reducing | No |
| Seal Material | EPDM |
| Series | POWERPRESS Series |
| Shape | Bend 45º |
| Size | 2" |
| System Specific | Yes |
| Wall Thickness Connection 1 | 3.4 mm |
| With Buffer Stud | Yes |
| With Connection Indicator | Yes |
| With De-aerator | No |
| With Drain Valve | No |
| With Sealing Rings/gaskets | No |
| With Thermal Insulation | No |
| Working Length Connection 1 | 1.22" |
| Z1 | 1.22 |
| Zeta Value | 0.35 |
Shipping Info:
| Ship weight (kg) | 0.98 |
| Ship height (cm) | 7.39 |
| Ship length (cm) | 11.51 |
| Ship width (cm) | 12.7 |
| Country of Origin | NL |
Documentation:
Product Variants
| Model | Size | Dimensions | Length Of Connection 2 | Length Of Connection 1 | Working Length Connection 1 | Wall Thickness Connection 1 | Outside Pipe Dia. 2 | Outside Pipe Dia. 1 | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| PWR7481540 | 3/4" | 2 13/25" x 2 13/25" x 1 1/2" | 1.79" | 1.79" | 0.57" | 2.7 mm | 1.05" | 1.05" | €54.02 | |
| PWR7481551 | 1" | 2.99" x 2.99" x 1.81" | 2.11" | 2.11" | 0.69" | 2.9 mm | 1.31" | 1.31" | €67.56 | |
| PWR7481584 | 2" | 4 4/5" x 4 4/5" x 2.91" | 3.29" | 3.29" | 1 1/5" | 3.4 mm | 2.37" | 2.37" | €212.05 | |
| PWR7481531 | 1/2" | 2 1/5" x 2 1/5" x 1.3" | 1.59" | 1.59" | 0.49" | 2.7 mm | 21/25" | 21/25" | €44.76 | |
| PWR7481628 | 1 1/4" | 3.62" x 3.94" x 2 1/5" | 3 6/25" | 2.78" | 0.89" | 2.9 mm | 1.66" | 1.66" | €120.19 | |
| PWR7481562 | 1 1/4" | 3.82" x 3.82" x 2 1/5" | 2.78" | 2.78" | 0.89" | 2.9 mm | 1.66" | 1.66" | €156.28 | |
| PWR7481639 | 1 1/2" | 4.29" x 4.09" x 2 11/25" | 3.35" | 3.31" | 1.38" | 3.4 mm | 1.9" | 1.9" | €150.72 |
