APOLLO VALVES PWR7480154 Elbow, 1-1/4 Inch Size, 90 Degree, Powerpress
Get it by Tuesday, Dec 23
€121.61 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Elbow, 90 Degree |
| Bend Angle | 90° |
| Bend Radius | 1.77" |
| Capped | Yes |
| Color | Gray |
| Connection Type | Press |
| Contour Code | DW |
| D1 | 1.66 |
| D2 | 1.66 |
| Dimensions | 4.92" x 4.92" x 2 1/5" |
| Eccentric | No |
| Finish | Zinc Nickel Plated |
| Flange Compression Class | PN 16 |
| Grade | Grade St 35 |
| High Tensile Strength | Yes |
| Intrastat Code | 73079980 |
| Length | 125 mm |
| Length Of Connection 1 | 3 4/5" |
| Length Of Connection 2 | 3 4/5" |
| Material | Steel |
| Max. Media Temp. | 275°F |
| Max. Operating Pressure Liquid | 232 psi |
| Medium Temp. (continuous) | -40°F to +275°F |
| Min. Media Temp. | -40°F |
| Outer Pipe Dia. 1 | 1.66" |
| Outer Pipe Dia. 2 | 1.66" |
| Peak Media Temp. | 302°F |
| Product Datasheet | apollo-valves-pwr7480154.pdf |
| Reducing | No |
| Seal Material | EPDM |
| Series | POWERPRESS Series |
| Shape | Bend 90º |
| Size | 1 1/4" |
| System Specific | Yes |
| Wall Thickness Connection 1 | 2.9 mm |
| Wall Thickness Connection 2 | 2.9 mm |
| With Buffer Stud | Yes |
| With Connection Indicator | Yes |
| With De-aerator | No |
| With Drain Valve | No |
| With Sealing Rings/gaskets | No |
| With Thermal Insulation | No |
| Working Length Connection 1 | 1.91" |
| Working Length Connection 2 | 1.91" |
| Z1 | 1.91 |
| Z2 | 1.91 |
| Zeta Value | 0.51 |
Shipping Info:
| Ship weight (kg) | 0.6 |
| Ship height (cm) | 5.59 |
| Ship length (cm) | 12.5 |
| Ship width (cm) | 12.5 |
| Country of Origin | NL |
Documentation:
Product Variants
| Model | Connection Type | Size | Material | Color | Price | |
|---|---|---|---|---|---|---|
| PWR7481430 | Press | 1" | Steel | Gray | €75.89 | |
| PWR7481421 | Press | 3/4" | Steel | Gray | €63.52 | |
| PWR7481419 | Press | 1/2" | Steel | Gray | €56.03 | |
| PWR7481441 | Press | 1 1/4" | Steel | Gray | €130.07 | |
| PWR7481452 | Press | 1 1/2" | Steel | Gray | €131.88 | |
| PWR7481463 | Press | 2" | Steel | Gray | €196.10 | |
| PWR7481507 | Press x Tube End | 1 1/4" | Steel | Gray | €104.18 |
