VESTIL AHA Series Adjustable Height Aluminium Gantry Cranes
Filter
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
V
W
X
Y
Z
A1
B1
C1
D1
E1
F1
G1
H1
I1
J1| Style | Model | Beam Height | Height | Usable Span | I Beam Length | Caster Width | Max. Clearance | Usable Beam Length | Min. Clearance | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | AHA-4-15-10 | - | 102 1/8" | - | 180" | 2" | 122" | 156 1/4" | 92" | €9,169.08 | |
| B | AHA-2-8-12 | 6" | - | - | 96" | 2" | 144" | 72 1/4" | 114" | €2,917.90 | |
| C | AHA-2-10-10 | 6" | 98" | - | 120" | 2" | 122" | 96 1/4" | 92" | €4,784.39 | |
| D | AHA-2-10-12 | 6" | - | - | 120" | 2" | 144" | 96 1/4" | 114" | €3,153.41 | |
| E | AHA-2-10-8 | 6" | 74" | 8 ft. | 120" | 2" | 98" | 96 1/4" | 68" | €5,674.10 | |
| F | AHA-2-8-8 | 6" | 74" | 6 ft. | 96" | 2" | 98" | 72 1/4" | 68" | €3,975.90 | |
| G | AHA-2-8-10 | 6" | 98" | - | 96" | 2" | 122" | 72 1/4" | 92" | €2,781.15 | |
| H | AHA-4-12-10 | 8" | 100 1/8" | - | 144" | 2" | 122" | 120 1/4" | 92" | €7,393.30 | |
| I | AHA-2-15-12 | 8" | 122" | - | 180" | 2" | 144" | 156 1/4" | 114" | €7,684.63 | |
| J | AHA-4-12-12 | 8" | 122 1/8" | - | 144" | 2" | 144" | 120 1/4" | 114" | €5,113.62 | |
| K | AHA-2-15-8 | 8" | 76" | - | 180" | 2" | 98" | 156 1/4" | 68" | €7,040.50 | |
| L | AHA-4-8-8 | 8" | 76.187" | - | 96" | 2" | 98" | 72 1/4" | 68" | €5,483.86 | |
| M | AHA-4-8-12 | 8" | 122 1/8" | - | 96" | 2" | 144" | 72 1/4" | 114" | €6,355.92 | |
| N | AHA-4-8-10 | 8" | 100 1/8" | - | 96" | 2" | 122" | 72 1/4" | 92" | €3,821.62 | |
| O | AHA-4-10-8 | 8" | 76.187" | - | 120" | 2" | 98" | 96 1/4" | 68" | €6,582.21 | |
| P | AHA-4-10-12 | 8" | 122 1/8" | - | 120" | 2" | 144" | 96 1/4" | 114" | €4,834.69 | |
| Q | AHA-4-10-10 | 8" | 100 1/8" | - | 120" | 2" | 122" | 96 1/4" | 92" | €4,460.15 | |
| R | AHA-2-12-10 | 8" | 100" | - | 144" | 2" | 122" | 120 1/4" | 92" | €3,391.04 | |
| S | AHA-2-15-10 | 8" | 100" | - | 180" | 2" | 122" | 156 1/4" | 92" | €7,353.89 | |
| T | AHA-4-12-8 | 8" | 76.187" | - | 144" | 2" | 98" | 120 1/4" | 68" | €4,453.78 | |
| U | AHA-2-12-12 | 8" | 122" | - | 144" | 2" | 144" | 120 1/4" | 114" | €3,559.60 | |
| V | AHA-2-12-8 | 8" | 76" | - | 144" | 2" | 98" | 120 1/4" | 68" | €5,135.37 | |
| W | AHA-6-8-10 | 10" | 132" | - | 96" | 3" | 122" | 72 1/4" | 98" | €5,610.04 | |
| X | AHA-6-8-12 | 10" | 156" | - | 96" | 3" | 146" | 72 1/4" | 122" | €5,657.72 | |
| Y | AHA-4-15-12 | 10" | 124 1/8" | - | 180" | 2" | 144" | 156 1/4" | 114" | €6,143.57 | |
| Z | AHA-6-8-8 | 10" | - | - | 96" | 3" | 98" | 72 1/4" | 74" | €5,276.97 | |
| A1 | AHA-4-15-8 | 10" | 78.187" | - | 180" | 2" | 98" | 156 1/4" | 68" | €5,321.48 | |
| B1 | AHA-6-10-8 | 10" | - | - | 120" | 3" | 98" | 96 1/4" | 74" | €5,996.06 | |
| C1 | AHA-6-10-12 | 10" | 156" | - | 120" | 3" | 146" | 96 1/4" | 122" | €6,234.73 | |
| D1 | AHA-6-10-10 | 10" | 132" | - | 120" | 3" | 122" | 96 1/4" | 98" | €6,108.55 | |
| E1 | AHA-6-12-10 | 12" | 134" | - | 144" | 3" | 122" | 120 1/4" | 98" | €6,257.06 | |
| F1 | AHA-6-15-12 | 12" | 158" | - | 180" | 3" | 146" | 156 1/4" | 122" | €7,022.84 | |
| G1 | AHA-6-12-8 | 12" | 110" | - | 144" | 3" | 98" | 120 1/4" | 74" | €5,930.41 | |
| H1 | AHA-6-15-8 | 12" | 110" | - | 180" | 3" | 98" | 156 1/4" | 74" | €6,782.15 | |
| I1 | AHA-6-15-10 | 12" | 134" | - | 180" | 3" | 122" | 156 1/4" | 98" | €6,926.33 | |
| J1 | AHA-6-12-12 | 12" | 158" | - | 144" | 3" | 146" | 120 1/4" | 122" | €10,362.86 |
AHA Series Adjustable Height Aluminium Gantry Cranes
Vestil AHA Series adjustable height aluminium gantry cranes are portable lifting equipment designed to provide a flexible & efficient solution for lifting & moving heavy loads. They are suitable for efficient load handling in workshops, warehouses and construction sites. These gantry cranes include two straps for easy convenience. They feature aluminium construction to ensure extended operational life. They come with four swivel glass-filled nylon casters, each fitted with four-way position locks to ensure secure positioning. These units offer fork trucks or other overhead lifting devices for conveniently adjustable height.
