OSG Cobalt Jobber Length Drill Bits
Filter
A
B
C
D
E| Style | Model | Decimal Equivalent | Flute Length | Max. Drilling Depth | Shank Dia. | Overall Length | Drill Bit Size | Shank Length | Drill Diameter Tolerance | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 15086005 | 0.086 | 1 1/8" | 1 1/8" | 1/8" | 2 3/8" | #44 | 32 mm | -0.014 mm to 0 mm | €31.68 | |
| A | 15093505 | 0.0935 | 1 1/4" | 1 1/4" | 1/8" | 2 1/2" | #42 | 32 mm | -0.014 mm to 0 mm | €33.13 | |
| B | 15093805 | 0.0938 | 1 1/4" | 1 1/4" | 1/8" | 2 1/2" | 3/32" | 32 mm | -0.014 mm to 0 mm | €34.06 | |
| A | 15098005 | 0.098 | 1 3/8" | 1 3/8" | 1/8" | 2 5/8" | #40 | 32 mm | -0.014 mm to 0 mm | €33.07 | |
| C | 15500005 | 0.5 | 4 1/2" | 4 1/2" | 1/2" | 6 19/32" | 1/2" | 53 mm | -0.027 mm to 0 mm | €220.46 | |
| A | 15120005 | 0.12 | 1 5/8" | 1 5/8" | 0.188" | 3 1/16" | #31 | 36 mm | -0.018 mm to 0 mm | €34.39 | |
| A | 15250005 | 0.25 | 2 3/4" | 2 3/4" | 1/4" | 4 9/16" | 1/4" | 46 mm | -0.022 mm to 0 mm | €82.77 | |
| D | 15750005 | 0.75 | 5 7/8" | 5 7/8" | 7/8" | 8 17/32" | 3/4" | 67 mm | -0.033 mm to 0 mm | €655.37 | |
| A | 15136005 | 0.136 | 1 3/4" | 1 3/4" | 0.188" | 3 3/16" | #29 | 36 mm | -0.018 mm to 0 mm | €42.53 | |
| A | 15159005 | 0.159 | 2 1/8" | 2 1/8" | 0.188" | 3.562" | - | 37 mm | - | €48.61 | |
| A | 15177005 | 0.177 | 2 3/16" | 2.188" | 0.188" | 3 5/8" | #16 | 37 mm | -0.018 mm to 0 mm | €48.61 | |
| A | 15196005 | 0.196 | 2 7/16" | 2 7/16" | 1/4" | 4 1/4" | #9 | 46 mm | -0.018 mm to 0 mm | €50.53 | |
| A | 15199005 | 0.199 | 2 7/16" | 2 7/16" | 1/4" | 4 1/4" | #8 | 46 mm | -0.018 mm to 0 mm | €49.81 | |
| A | 15201005 | 0.201 | 2 7/16" | 2 7/16" | 1/4" | 4 1/4" | #7 | 46 mm | -0.018 mm to 0 mm | €51.71 | |
| A | 15213005 | 0.213 | 2 1/2" | 2 1/2" | 1/4" | 4 5/16" | #3 | 46 mm | -0.018 mm to 0 mm | €70.70 | |
| A | 15257005 | 0.257 | 2 7/8" | 2 7/8" | 3/8" | 4 11/16" | F | 46 mm | -0.022 mm to 0 mm | €86.88 | |
| C | 15316005 | 0.316 | 3 3/16" | 3 3/16" | 3/8" | 5" | O | 47 mm | -0.022 mm to 0 mm | €119.19 | |
| C | 15332005 | 0.332 | 3 7/16" | 3 7/16" | 3/8" | 5 1/4" | Q | 46 mm | -0.022 mm to 0 mm | €116.27 | |
| C | 15339005 | 0.339 | 3 7/16" | 3.438" | 3/8" | 5 1/4" | R | 46 mm | -0.022 mm to 0 mm | €155.70 | |
| C | 15348005 | 0.348 | 3 1/2" | 3 1/2" | 3/8" | 5 5/16" | S | 46 mm | -0.022 mm to 0 mm | €149.16 | |
| D | 15375005 | 0.375 | 3 5/8" | 3 5/8" | 3/8" | 5 7/16" | 3/8" | 46 mm | -0.022 mm to 0 mm | €139.58 | |
| C | 15625005 | 0.625 | 5 3/16" | 5 3/16" | 3/4" | 7 27/32" | 5/8" | 68 mm | -0.027 mm to 0 mm | €438.77 | |
| A | 15109405 | 0.1094 | 1 1/2" | 1 1/2" | 0.188" | 2 15/16" | 7/64" | 36 mm | -0.014 mm to 0 mm | €35.51 | |
| A | 15128505 | 0.1285 | 1 5/8" | 1 5/8" | 0.188" | 3 1/16" | #30 | 36 mm | -0.018 mm to 0 mm | €31.65 | |
| A | 15140605 | 0.1406 | 1 3/4" | 1 3/4" | 0.188" | 3 3/16" | 9/64" | 36 mm | -0.018 mm to 0 mm | €43.72 | |
| A | 15156205 | 0.1563 | 2" | 2" | 0.188" | 3 7/16" | 5/32" | 37 mm | -0.018 mm to 0 mm | €45.78 | |
| A | 15171905 | 0.1719 | 2 1/8" | 2 1/8" | 0.188" | 3 9/16" | 11/64" | 37 mm | -0.018 mm to 0 mm | €50.09 | |
| B | 15187505 | 0.1875 | 2 5/16" | 2 5/16" | 0.188" | 3 3/4" | 3/16" | 37 mm | -0.018 mm to 0 mm | €54.16 | |
| A | 15203105 | 0.2031 | 2 7/16" | 2 7/16" | 1/4" | 4 1/4" | 13/64" | 46 mm | -0.018 mm to 0 mm | €54.16 | |
| A | 15218805 | 0.2188 | 2 1/2" | 2 1/2" | 1/4" | 4 5/16" | 7/32" | 46 mm | -0.018 mm to 0 mm | €70.70 | |
| A | 15234405 | 0.2344 | 2 5/8" | 2 5/8" | 1/4" | 4 7/16" | 15/64" | 46 mm | -0.018 mm to 0 mm | €77.05 | |
| A | 15265605 | 0.2656 | 2 7/8" | 2 7/8" | 3/8" | 4 11/16" | 17/64" | 46 mm | -0.022 mm to 0 mm | €96.02 | |
| A | 15281205 | 0.2813 | 2 15/16" | 2 15/16" | 3/8" | 4 3/4" | 9/32" | 46 mm | -0.022 mm to 0 mm | €108.31 | |
| A | 15296905 | 0.2969 | 3 1/16" | 3 1/16" | 0.297" | 4 7/8" | 19/64" | 46 mm | -0.022 mm to 0 mm | €108.31 | |
| C | 15312505 | 0.3125 | 3 3/16" | 3 3/16" | 3/8" | 5" | 5/16" | 47 mm | -0.022 mm to 0 mm | €132.40 | |
| C | 15328105 | 0.3281 | 3 5/16" | 3 5/16" | 3/8" | 5 1/8" | 21/64" | 46 mm | -0.022 mm to 0 mm | €122.76 | |
| C | 15343805 | 0.3438 | 3 7/16" | 3.438" | 3/8" | 5 1/4" | 11/32" | 46 mm | -0.022 mm to 0 mm | €153.32 | |
| C | 15359405 | 0.3594 | 3 1/2" | 3 1/2" | 3/8" | 5 5/16" | 23/64" | 46 mm | -0.022 mm to 0 mm | €172.81 | |
| C | 15390605 | 0.3906 | 3 3/4" | 3 3/4" | 1/2" | 5 27/32" | 25/64" | 53 mm | -0.022 mm to 0 mm | €160.37 | |
| C | 15406205 | 0.4063 | 3 7/8" | 3 7/8" | 1/2" | 5 31/32" | 13/32" | 53 mm | -0.027 mm to 0 mm | €160.37 | |
| C | 15421905 | 0.4219 | 3 15/16" | 3 15/16" | 1/2" | 6 1/32" | 27/64" | 53 mm | -0.027 mm to 0 mm | €181.63 | |
| C | 15437505 | 0.4375 | 4 1/16" | 4.062" | 1/2" | 6 5/32" | 7/16" | 53 mm | -0.027 mm to 0 mm | €181.21 | |
| C | 15453105 | 0.4531 | 4 3/16" | 4 3/16" | 1/2" | 6 9/32" | 29/64" | 53 mm | -0.027 mm to 0 mm | €186.82 | |
| C | 15468805 | 0.4688 | 4 5/16" | 4.312" | 1/2" | 6 13/32" | 15/32" | 53 mm | -0.027 mm to 0 mm | €195.71 | |
| D | 15484405 | 0.4844 | 4 3/8" | 4 3/8" | 1/2" | 6 15/32" | 31/64" | 53 mm | -0.027 mm to 0 mm | €214.43 | |
| C | 15531205 | 0.5313 | 4 13/16" | 4 13/16" | 5/8" | 7 3/16" | 17/32" | 60 mm | -0.027 mm to 0 mm | €406.16 | |
| C | 15562505 | 0.5625 | 4 13/16" | 4 13/16" | 5/8" | 7 3/16" | 9/16" | 60 mm | -0.027 mm to 0 mm | €425.73 | |
| E | 15578105 | 0.5781 | 4 13/16" | 4.812" | 5/8" | 7 3/16" | 37/64" | 60 mm | -0.027 mm to 0 mm | €391.68 | |
| C | 15593805 | 0.5938 | 5 3/16" | 5.188" | 3/4" | 7 27/32" | 19/32" | 68 mm | -0.027 mm to 0 mm | €487.28 | |
| C | 15656205 | 0.6563 | 5 3/16" | 5 3/16" | 3/4" | 7 27/32" | 21/32" | 68 mm | -0.027 mm to 0 mm | €496.51 | |
| C | 15687505 | 0.6875 | 5 5/8" | 5 5/8" | 3/4" | 8 9/32" | 11/16" | 68 mm | -0.027 mm to 0 mm | €574.70 | |
| D | 15718805 | 0.7188 | 5 5/8" | 5 5/8" | 7/8" | 9.281" | - | 93 mm | - | €570.04 |
