Toggle Clamp Spindle Assemblies

Destaco swivel foot spindles are used in straight-line action clamps and consist of an internal compression spring to adjust thickness according to the material. They are available in different thread sizes, heights and swivel angles.

These Destaco flat tip bonded neoprene spindles are threaded rods with rubber stoppers used to secure materials to work surfaces. These toggle clamp spindle assemblies can be adjusted to accommodate materials of varying thicknesses and can mount onto compatible toggle clamps (including manual, power & hydraulic clamps) to protect them from damage caused by abrasion / twisting / flexing, as well as to ensure optimal functionality and performance during welding, drilling and milling operations in the aerospace, automotive and food & packaging industries. When the rubber stoppers begin to wear away, these spindles eliminate the risk of marring owing to the neoprene constructed tips. The neoprene construction of these spindles exhibit chemical stability by maintaining flexibility over a wide temperature range (-22 degrees to 220 degrees Fahrenheit). They also ensure extended service life and provide maximum clamping force. These oil resistant and silicone free spindles include jam nuts to permit clamping distance adjustments as well as facilitate easy and secure installation. These spindles offer hardness up to 85 Shore A and are available in #8-32, #10-32, 1/4-20, 5/16-18, 1/2-13, 5/8-11, 3/8-16, M6, M8, M10 and M12 thread size variants for quick fastening, on Raptor Supplies.
We also offer spindles in stainless steel construction for corrosion resistant performance. If you want to order these, simply request a quote for the same on Raptor Supplies.
