ZURN 2-350XL Backflow Preventer, Bronze, MNPT Connection
Get it by Monday, Aug 31
5.00% off
€1,615.30 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Backflow Preventer |
| Backflow Preventer Type | Double Check Assembly (Dc) |
| Body Material | Bronze |
| Configuration | Standard Configuration |
| Connection Size-side 1 | 2" |
| Connection Size-side 2 | 2" |
| Connection Type | Flange x Flange |
| Connection Type-side 1 | Flange |
| Connection Type-side 2 | Flange |
| Features | Low Lead Design Is Suitable For Drinking Water, Patented Removable Pressure Vessel, Top Mounted Test Cocks Ease Installation |
| Flow Rate | 253 GPM |
| For Media | Water |
| Handle Material | Stainless Steel |
| Hazard Protection Level | Low Health Hazard |
| Included Freeze Protection | No Freeze Sensor |
| Included Strainer | No |
| Length | 26" |
| Material | Bronze |
| Max. Media Temp. | 180°F |
| Max. Pressure | 175 psi |
| Max. Pressure (cwp) | 175 psi |
| Max. Temp. | 180°F |
| Media Temp. | 33°F to 180°F |
| Min. Media Temp. | 33°F |
| Mounting Orientation | Horizontal, Vertical |
| Overall Height | 6" |
| Overall Length | 16" |
| Overall Width | 6 1/4" |
| Pipe Size | 2" |
| Product Datasheet | zurn-1-350lxldmft.pdf |
| Protection Type | Back Pressure, Back Siphonage |
| Shut-off Valve Type | Ball Valve |
| Spring Material | Stainless Steel |
| Temp. | +33°F to +180°F |
Shipping Info:
| Ship weight (kg) | 10.8 |
| Ship height (cm) | 15.88 |
| Ship length (cm) | 66.04 |
| Ship width (cm) | 5.72 |
| Country of Origin | CN |
Documentation:
Product Variants
| Product | Model | Connection Type-side 1 | Connection Size-side 1 | Connection Size-side 2 | Connection Type-side 2 | Flow Rate | Overall Height | Overall Width | Height | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
112-350XL | Flange | 1 1/2" | 1 1/2" | Flange | 150 GPM | 6" | 6 1/4" | 6 1/4" | €1,508.50 | |
|
114-350XL | NPTF | 1 1/4" | 1 1/4" | NPTF | 253 GPM | 6" | 6 1/4" | - | €1,405.79 | |
 |
1-350XL | - | - | - | - | - | - | - | 4 1/8" | €663.29 | |
 |
34-350XL | Flange | 3/4" | 3/4" | Flange | 43 GPM | 4 1/4" | 3 3/4" | 3 3/4" | €605.30 |
