WIDIA VDS402A05558 Jobber Length Drill Bit, 7/32 Inch Size Size, Carbide
Item: CV2WDHModel: VDS402A05558Cross Ref: 431Z54
7 In Stock
Ships within 2 days via
10.00% off
€133.16 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Jobber Length Drill Bit |
| Coolant Fed | Coolant Through |
| Coolant Through | Yes |
| Cutting Direction | Right Hand |
| Decimal Equivalent | 0.2188 |
| Depth X Dia. Ratio | 5xd |
| Drill Bit Dimension Type | Fractional Inch |
| Drill Bit Grouping | Drill Bit |
| Drill Bit Material | Carbide |
| Drill Bit Point Angle | 140° |
| Drill Bit Point Type | Conical Point |
| Drill Bit Size | 7/32" |
| Drill Diameter Tolerance | H7 |
| Drill Length Class | Jobber Length |
| Drill Point Length | 0.037" |
| Finish | Titanium Aluminum Nitride Coat |
| Finish - Machining | TiAlN |
| Flute Length | 1 11/16" |
| Flute Type | Helical |
| Grade | Grade WU25PD |
| Helix Angle | 28° |
| List Number | 402 |
| Material | Carbide |
| Material - Machining | Carbide |
| Material Grade - Machining | Grade WU25PD |
| Max. Drilling Depth | 1 3/8" |
| Mfr. Series | VDS402 Series |
| No. Of Pieces | 1 |
| Number Of Coolant Holes | 2 |
| Number Of Flutes | 2 |
| Overall Length | 3 7/32" |
| Point Angle | 140° |
| Point Type | Conical Point |
| Primary Material Application | Aluminum, Cast Iron, Nickel, Stainless Steel, Steel, Titanium |
| Primary Material Application Iso Code | K, M, N, P, S |
| Shank Dia. | 0.234" |
| Shank Diameter | 15/64" |
| Shank Length | 1 13/32" |
| Shank Type | Straight |
| Shank Type - Machining | Straight |
| Sheeter Drill | No |
| Size | 0.219" |
| Spiral Direction | Right Hand |
| System Of Measurement | Fractional Inch |
Shipping Info:
| Ship weight (kg) | 0.02 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 8.18 |
| Ship width (cm) | 2.54 |
Product Variants
| Product | Model | Shank Dia. | Flute Type | Overall Length | Max. Drilling Depth | Flute Length | Decimal Equivalent | Drill Bit Size | Drill Bit Point Type | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
4158001 | 0.234" | Helical | - | - | - | - | #11 | Split Point | €133.44 | |
 |
4157025 | 0.234" | Spiral | 3 11/16" | 1 7/8" | 2 3/16" | - | #11 | TDS Point | €252.72 | |
 |
TDS412A04852 | 0.234" | Spiral | 3 7/32" | 1 3/8" | 1 11/16" | 0.191 | #11 | TDS Point | €154.15 | |
 |
VDS402A04852 | 0.234" | Helical | 3 7/32" | 1 3/8" | 1 11/16" | - | #11 | Conical Point | €140.24 | |
 |
4143779 | 6 mm | Helical | 94 mm | 48 mm | 56 mm | 0.191 | #11 | Conical Point | €224.13 | |
 |
TDS413A04800 | 0.234" | Spiral | 3 11/16" | 1 7/8" | 2 3/16" | 0.189 | #12 | TDS Point | €240.43 | |
|
TDS403A04800 | 0.234" | Spiral | 3 11/16" | 1 7/8" | 2 3/16" | 0.189 | #12 | TDS Point | €236.18 |
