WIDIA TDS403A03264 Jobber Length Drill Bit, #30 Size, 3 1/16 Inch Overall Length
Item: CV2UTBModel: TDS403A03264Cross Ref: 432R16
7 In Stock
Ships within 2 days via
10.00% off
€206.21 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Jobber Length Drill Bit |
| Application | Metalworking |
| Coolant Fed | Coolant Through |
| Coolant Through | Yes |
| Cutting Direction | Right Hand |
| Decimal Equivalent | 0.1285 |
| Depth X Dia. Ratio | 8xd |
| Drill Bit Dimension Type | Wire |
| Drill Bit Grouping | Drill Bit |
| Drill Bit Material | Carbide |
| Drill Bit Point Angle | 140° |
| Drill Bit Point Type | TDS Point |
| Drill Bit Size | #30 |
| Drill Diameter Tolerance | M7 |
| Drill Length Class | Jobber Length |
| Drill Point Length | 0.0208" |
| Finish | Titanium Aluminum Nitride Coat |
| Finish - Machining | TiAlN |
| Flute Length | 1 9/16" |
| Flute Type | Spiral |
| Grade | Grade WP20PD |
| Helix Angle | 29° |
| Material | Carbide |
| Material - Machining | Carbide |
| Material Grade - Machining | Grade WP20PD |
| Max. Drilling Depth | 1.297" |
| Maximum Drilling Depth | 1 19/64" |
| Measurement System | Wire |
| Mfr. Series | TDS403 Series |
| No. Of Pieces | 1 |
| Number Of Coolant Holes | 2 |
| Number Of Flutes | 2 |
| Overall Length | 3 1/16" |
| Point Angle | 140° |
| Point Type | TDS Point |
| Primary Material Application | Steel |
| Primary Material Application Iso Code | P |
| Shank Dia. | 0.234" |
| Shank Diameter | 15/64" |
| Shank Length | 1 13/32" |
| Shank Type | Straight |
| Shank Type - Machining | Straight |
| Sheeter Drill | No |
| Size | #30 |
| Spiral Direction | Right Hand |
Shipping Info:
| Ship weight (kg) | 0.02 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 7.77 |
| Ship width (cm) | 2.54 |
| Country of Origin | DE |
Product Variants
| Product | Model | Shank Dia. | Flute Type | Overall Length | Max. Drilling Depth | Flute Length | Decimal Equivalent | Drill Bit Size | Drill Bit Point Type | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
4158001 | 0.234" | Helical | - | - | - | - | #11 | Split Point | €133.44 | |
 |
4157025 | 0.234" | Spiral | 3 11/16" | 1 7/8" | 2 3/16" | - | #11 | TDS Point | €252.72 | |
 |
TDS412A04852 | 0.234" | Spiral | 3 7/32" | 1 3/8" | 1 11/16" | 0.191 | #11 | TDS Point | €154.15 | |
 |
VDS402A04852 | 0.234" | Helical | 3 7/32" | 1 3/8" | 1 11/16" | - | #11 | Conical Point | €140.24 | |
 |
4143779 | 6 mm | Helical | 94 mm | 48 mm | 56 mm | 0.191 | #11 | Conical Point | €224.13 | |
|
TDS413A04800 | 0.234" | Spiral | 3 11/16" | 1 7/8" | 2 3/16" | 0.189 | #12 | TDS Point | €240.43 | |
|
TDS403A04800 | 0.234" | Spiral | 3 11/16" | 1 7/8" | 2 3/16" | 0.189 | #12 | TDS Point | €236.18 |
