WEG CWC07-00-22V18 13181131 Miniature Contactor, 7 A, 2 NO, 2 NC Main Contact, 110V 50Hz/120V 60Hz
Item: BC7QGWModel: CWC07-00-22V18Cross Ref: 13181131
7 In Stock
Ships within 2 days via
€28.07 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Contactor |
| Actuator Type | Magnetic |
| Coil Frequency | 50/60 Hz |
| Coil Type | Magnetic |
| Coil Voltage | 120/110V AC , 120V AC |
| Contact Type | NO/NC |
| Contactor Type | IEC Miniature |
| Control Voltage | 110/120V |
| Depth | 2.05" |
| Electrical Lifespan | 1.4 Million Cycles |
| Frequency | 60/50 Hz |
| Gross Weight | 0.44 lbs. |
| Height | 2.28" |
| Main Contacts | NO, NC |
| Max Hp 120v 1ph | 33/100 hp |
| Max Hp 200/208v 3ph | 1 1/2 hp |
| Max Hp 230/240v 1ph | 3/4 hp |
| Max Hp 230/240v 3ph | 1 1/2 hp |
| Max Hp 460/480v 3ph | 5 hp |
| Max Hp 575/600v 3ph | 5 hp |
| Max. Rated Operational Frequency | 25 Hz |
| Mechanical Lifespan (ac) | 10 Milion Cycles |
| Mechanical Lifespan (dc) | 12 Milion Cycles |
| Min. Rated Operational Frequency | 400 Hz |
| No. Of Contacts | 2 NO, 2 NC |
| Nominal Coil Voltage | 120V AC |
| Number Of Contacts | 4 |
| Number Of Poles | 4 |
| Power Poles | NO/NC |
| Rated Current | 7A |
| Rated Insulation Voltage | 1000V |
| Rated Operational Amps Ie Ac-1 | 18A |
| Rated Operational Voltage | 690V |
| Series | CWC Series |
| Terminal Type | Screw |
| Termination | Screw |
| Width | 1.77" |
Shipping Info:
| Ship weight (kg) | 0.18 |
| Ship height (cm) | 6.35 |
| Ship length (cm) | 9.4 |
| Ship width (cm) | 6.35 |
| Country of Origin | BR |
Product Variants
| Product | Model | Number Of Poles | Depth | Height | Contactor Type | Price | |
|---|---|---|---|---|---|---|---|
 |
CWC09-01-30V24-X50 | - | 2.05" | 2.28" | - | €30.41 | |
|
CWC09-10-30V24-X50 | - | 2.05" | 2.28" | - | €30.41 | |
 |
CWC07-00-40L03 | 4 | 2.05" | 2.28" | IEC Miniature | €36.25 | |
 |
CWC012-10-30L02 | 3 | 2.05" | 2.28" | IEC Miniature | - | RFQ
|
 |
CWC09-00-40L03 | 4 | 2.05" | 2.28" | IEC Miniature | €44.10 | |
 |
CWC09-10-30L02 | 3 | 2.05" | 2.28" | IEC Miniature | €43.20 | |
 |
CWC09-00-40L02 | 4 | 2.05" | 2.28" | IEC Miniature | €44.10 |
