WARNER ELECTRIC 5371-169-102 EM-215-20 24V C-face Brake Torque 95 Ft-lb 24 Vdc, 8.06 Inch Length
Get it by Wednesday, Aug 26
€3,622.07 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Brake |
| Brake Mouting Position | Horizontal |
| Clutch/brake Type | Magnetic Clutch, Brake |
| Coil Voltage | 24V DC |
| Dc Voltage | 90 |
| Enclosure Type | Vented |
| Finish | Black Paint |
| For Use With | NEMA C Face Motor, Reducer |
| Housing Material Finish | Black Paint |
| Included | Mounting Hardware |
| Length | 8 1/16" |
| Max. Speed | 3600 RPM |
| Mounting Location | NEMA C-Face Motor Or Between Motor And Reducer |
| Mounting Orientation | Horizontal |
| Mounts On | NEMA C-Face Motor or Between Motor and Reducer |
| Mounts On | NEMA C Face Motor, Between Motor And Reducer |
| Nema/iec Frame | 213TC/215TC |
| Overall Length | 8.06" |
| Overall Width | 9.31" |
| Power Lead Length | 30" |
| Power Lead Length (in.) | 30 |
| Shaft Dia. | 1 3/8" |
| Static Torque | 95 lbs.-ft. |
| Static Torque | 95 Ft.-Lb. |
| Type | C Face |
| Voltage (dc) | 90 |
| Width | 9 5/16" |
Shipping Info:
| Ship weight (kg) | 12.24 |
| Ship height (cm) | 34.54 |
| Ship length (cm) | 46.74 |
| Ship width (cm) | 34.04 |
| HS code | 8505200000 |
| Country of Origin | US |
