VERSA-MATIC E1AA2R229C-ATEX Double Diaphragm Pump, Max 49 gpm, 125 psi
Get it by Friday, Feb 20
€ 24,99 Flat Shipping + VAT € 24,99 flat shipping is applicable on orders with an aggregate weight less than 10kg. Orders exceeding 10kg will be charged default shipping rates.
10.00% off
€2,224.75 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Double Diaphragm Pump |
| Air Consumption | 50 SCFM |
| Air Inlet Size | 3/8" |
| Air Inlet Type | NPT |
| Ball Material | Buna N |
| Center Section Material | Aluminum |
| Check Seat Material | Aluminum |
| Compatible Chemicals | Alcohol, Ammonium Hydroxide, Antifreeze, Diesel, Diesel Exhaust Fluid, Gasoline, Kerosene, Water |
| Diaphragm Material | Buna N |
| Display Qty | 1 |
| Duty Cycle | Continuous |
| Flow Rate @ 100 Psi | 48.2 GPM |
| Flow Rate @ 20 Psi | 26.5 GPM |
| Flow Rate @ 40 Psi | 36.4 GPM |
| Flow Rate @ 60 Psi | 40.8 GPM |
| Flow Rate @ 80 Psi | 45.4 GPM |
| Fluid Discharge Connection Size | 1" |
| Fluid Discharge Connection Type | NPT |
| Fluid Intake Connection | 1" |
| Fluid Intake Connection Type | NPT |
| For Use With Potable Systems | No |
| Height | 14 35/64" |
| Housing Material | Aluminum |
| Inlet Size | 1" |
| Length | 9 21/64" |
| Manifold Connection | Single Port |
| Manifold Connection Type | NPT |
| Manufacturers Warranty Length | 1 yr. |
| Max. Discharge Pressure | 125 psi |
| Max. Flow Gpm | 49 |
| Max. Flow Rate | 49 GPM |
| Max. Ft. | 320 ft. |
| Max. Media Temp. | 180°F |
| Max. Operating Pressure | 125 psi |
| Max. Solid Dia. | 0.13" |
| Max. Temp. | 180°F |
| Media Discharge Location | Center, Top |
| Media Intake Location | Bottom, Center |
| Operation Type | Air Operated |
| Outlet Size | 1" |
| Outlet Type | NPT |
| Overall Height | 14 1/2" |
| Overall Length | 9.1" |
| Overall Width | 10 4/5" |
| Power Source | Air |
| Priming | Self Priming |
| Pump Assembly Type | Bolt |
| Rated Air Pressure | 125 psi |
| Self Priming | Yes |
| Self Priming Dry | 16 ft. |
| Self Priming Wet | 31 ft. |
| Self-priming Dry | 16 ft. |
| Self-priming Wet | 31 ft. |
| Series | E1 Series |
| Series Family | E1 |
| Valve Material | Buna N |
| Valve Type | Ball |
| Width | 10 23/32" |
Shipping Info:
| Ship weight (kg) | 5.2 |
| Ship height (cm) | 27.94 |
| Ship length (cm) | 35.56 |
| Ship width (cm) | 40.64 |
| HS code | 8413500050 |
| Country of Origin | US |
Product Details:
- Ideal for ink transfer, chemical feed, small-tank recirculation and spray gun transfer applications
- Can also be used in explosive atmospheres when properly grounded
- Elima-Matic air valve system to provide lube-free, non-stalling performance
- Provides a corrosion-resistant air passage section
- Self-priming operation to reduce manual efforts
Product Variants
| Product | Model | Max. Flow Rate | Diaphragm Material | Housing Material | Valve Material | Check Seat Material | Max. Solid Dia. | Max. Media Temp. | Pump Assembly Type | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
E5AP2R229C | 12 GPM | Buna N | Aluminum | Buna N | Aluminum | 0.06" | 180°F | Bolt | €2,311.86 | |
|
E5AP6X669C | 12 GPM | Santoprene | Aluminum | Santoprene | Aluminum | 0.06" | 300°F | Bolt | €2,287.18 | |
|
E5AP5T559C | 12 GPM | PTFE | Aluminum | PTFE | Aluminum | 0.06" | 220°F | Bolt | €2,492.97 | |
 |
E5SP2R229C | 12 GPM | Buna N | Stainless Steel | Buna N | Stainless Steel | 0.06" | 180°F | Bolt | €4,213.29 | |
|
E5SP6X669C | 12 GPM | Santoprene | Stainless Steel | Santoprene | Santoprene | 0.06" | 300°F | - | €4,121.41 | |
|
E5SP5T559C | 12 GPM | PTFE | Stainless Steel | PTFE | Stainless Steel | 0.06" | 220°F | Bolt | €4,710.19 | |
 |
E5PP2R259D | 11 GPM | Buna N | Polypropylene | Buna N | Polypropylene | 0.06" | 175°F | Bolt | €1,716.21 |
