TITAN PRO TRCFD505 Motor Dual Run Capacitor, Round, 440/370 VAC, 50/5 MFD, 4 7/16 Inch Overall Height
Item: AC4LARModel: TRCFD505Cross Ref: 30D647
7 In Stock
Ships within 2 days via
10.00% off
€23.40 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Motor Dual Run Capacitor |
| Capacitor Shape | Round |
| Capacitor Type | Motor Dual Run Capacitor |
| Capacitor Voltage | 440/370V AC |
| Case Height | 3 15/16" |
| Case Height | 3.562" |
| Case Material | Aluminum |
| Connection Type | Quick Connect |
| Cover Material | Steel |
| Dia. | 2 1/2" |
| Diameter | 2 1/2" |
| Eia Tolerance Code | A |
| Eia Ul Base | T |
| Eia Ul Base | A |
| For Use With | Electric Motors |
| Frequency | 50/60 Hz |
| Frequency Rating | 50/60 Hz |
| Max. Temp. | 70°C |
| Max. Temperature | 70°C |
| Microfarad Rating | 50 µF, 5 µF |
| Microfarad Rating | 50/5 |
| Min. Temp. | -40°C |
| Min. Temperature | -40°C |
| Motor Capacitor Type | Motor Dual Run Capacitor |
| Number Of Pieces | 1 |
| Number Of Terminals | 3 |
| Overall Depth | 2 1/2" |
| Overall Height | 4 7/16" |
| Overall Width | 2 1/2" |
| Shape | Round |
| Tab Width | 1/4" |
| Temp. Range | -40°C to +70°C |
| Terminal Connection Type | Male Quick-Connect |
| Terminal Design | Standard |
| Terminal Designations | Standard |
| Terminal Gender | Male |
| Terminal Tab Width | 1/4" |
| Terminal Type | Male |
| Voltage | 440/370V AC |
Shipping Info:
| Ship weight (kg) | 0.32 |
| Ship height (cm) | 10.92 |
| Ship length (cm) | 7.11 |
| Ship width (cm) | 6.86 |
| HS code | 8532100000 |
| Country of Origin | CN |
Product Variants
| Model | Voltage | Overall Height | Microfarad Rating | Dia. | Overall Width | Overall Depth | Terminal Type | Motor Capacitor Type | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| TOCFD154 | 440/370V AC | 2 7/8" | 15 µF, 4 µF | 1 3/4" | 2 11/16" | 1 3/4" | Male | Motor Dual Run Capacitor | €22.67 | |
| TOCFD155 | 440/370V AC | 3 3/16" | 15 µF, 5 µF | 1 3/4" | 2 11/16" | 1 3/4" | Male | - | €17.35 | |
| TOCFD2015 | 440/370V AC | 4 3/8" | 20 µF, 15 µF | - | 2 13/16" | 1 3/4" | Male | Motor Dual Run Capacitor | €26.66 | |
| TOCFD2510 | 440/370V AC | 4 3/8" | 25 µF, 10 µF | 1 3/4" | 2 13/16" | 1 3/4" | Male | Motor Dual Run Capacitor | €28.27 | |
| TOCFD255 | 440/370V AC | 3 31/32" | 25 µF, 5 µF | 1 3/4" | 2 13/16" | 1 3/4" | Male | Motor Dual Run Capacitor | €17.98 | |
| TOCFD2575 | 440/370V AC | 3 31/32" | 25 µF, 7.5 µF | 1 3/4" | 2 13/16" | 1 3/4" | Male | Motor Dual Run Capacitor | €30.14 | |
| TOCFD304 | 440/370V AC | 4 3/8" | 30 µF, 4 µF | 1 3/4" | 2 13/16" | 1 3/4" | Male | Motor Dual Run Capacitor | €28.97 |
