SUPCO SHP600475 High Pressure Switch Opens 600 Psi
Ships within 2 days via
Payment
Product Specifications:
| Item | High Pressure Switch |
| Application | High Limit |
| Body Material | Stainless Steel |
| Close (psi) | 475 |
| Closing Pressure | 475 psi |
| Contact Form | SPST |
| Electrical Connection Type | Hardwired |
| Function | Protects Compressor |
| Includes | 18" Wire Leads |
| Maximum Operating Temperature | 149°F |
| Minimum Operating Temperature | -31°F |
| Mounting | Remote |
| Nema Rating | 1 |
| Open (psi) | 600 |
| Open (psi) | 600 psi |
| Pressure Connection | 1/4" Female SAE |
| Pressure Connection Gender | Female |
| Pressure Connection Size | 1/4" |
| Pressure Connection Type | Flare |
| Pressure Range - Maximum | 600 psi |
| Pressure Range - Minimum | 475 psi |
| Pressure Range Adjustability | Fixed |
| Pressure Setting | High |
| Process Connection | 1/4" Female Flare |
| Product Datasheet | supco-shp600475.pdf |
| Product Type | High Pressure Control |
| Range | 0 psi to 650 psi |
| Rated Voltage | 120/240/24V AC |
| Rated Voltage Range | 12-120/208-240V AC |
| Reset | Auto |
| Reset Type | Automatic Reset |
| Switch Action | Open On Rise |
| Switch Type | SPST |
| Type | Low Pressure |
Shipping Info:
| Ship weight (kg) | 0.07 |
| Ship height (cm) | 4.06 |
| Ship length (cm) | 13.46 |
| Ship width (cm) | 8.89 |
| HS code | 8536509065 |
| Country of Origin | CN |
Product Details:
Supco SHP600475 high pressure switch is suitable to open and close a circuit when the pressure in a system reaches a certain level. They are useful in HVAC/R applications as they prevent damage to the system by shutting it down if the pressure gets too high.
Features:
- Supco SHP600475 high pressure switch has NEMA 1 enclosure for indoor usage.
- It includes 18-inch lead wires for easy connection with universal HVAC/R equipment.
- This switch has an operating temperature range of -35 to 149 degrees F.
Frequently Asked Questions:
Q. What are the different types of SPST switches?
A. There are two main types of SPST switches: toggle switches and pushbutton switches. Toggle switches have a lever that can be moved up or down to turn the circuit on or off. Pushbutton switches have a button that must be pressed to turn the circuit on or off.
Q. What safety precautions should I take while using an SPST switch?
A.
- Always turn off the power to the circuit before working on it.
- Do not overload the switch.
- Inspect the switch regularly for signs of wear or damage.
