SSI 0500-125TFI-B Triple Duty Check Valve Cast Iron 5 Inch
Get it by Friday, Aug 28
€1,209.90 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Triple Duty Check Valve |
| Ansi Flange Class | Class 125 |
| Application-valves | Process Piping |
| Body Material | Cast Iron |
| Check Mechanism | Disc |
| Class | Class 125 |
| Connection Size-side 1 | 5" |
| Connection Size-side 2 | 5" |
| Connection Type | Flanged |
| Connection Type-side 1 | Flange |
| Connection Type-side 2 | Flange |
| Cracking Pressure | 0.25 psi |
| Flow Design | Single |
| For Media | Steam, Water |
| Full Flow-valves | Yes |
| Material | Cast Iron |
| Max. Media Temp. | 300°F |
| Max. Pressure (cwp) | 200 psi |
| Max. Pressure-steam | 200 psi |
| Max. Temp. | 212°F |
| Media Temp. | 60°F to 300°F |
| Min. Media Temp. | 60°F |
| Mounting Orientation | Horizontal, Vertical |
| Mounting Orientation-check Valves | Horizontal, Vertical |
| Overall Height | 16 3/8" |
| Pipe Or Tube Size | 5" |
| Seal | Buna N |
| Seal Material | Buna N |
| Seat Material | Buna N |
| Silent Check | Silent |
| Size | 5" |
| Spring Material | Stainless Steel |
| Spring Material-check Valves | Stainless Steel |
| Valve Body Style | Straight |
Shipping Info:
| Ship weight (kg) | 72 |
| Ship height (cm) | 40.64 |
| Ship length (cm) | 66.04 |
| Ship width (cm) | 60.96 |
| HS code | 8481302010 |
| Country of Origin | CN |
Product Variants
| Model | Size | Connection Size-side 1 | Connection Size-side 2 | Overall Height | Pipe Or Tube Size | Pipe Or Tube Size-check Valves | Seat Material | For Media | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| 0200-125TFI-B | 2" | 2" | 2" | 9 5/8" | 2" | - | Buna N | Steam, Water | €271.53 | |
| 0250-125TFI-B | 2 1/2" | 2 1/2" | 2 1/2" | 10" | - | - | Buna N | Steam, Water | €319.15 | |
| 0300-125TFI-B | 3" | 3" | 3" | 10 1/8" | 3" | - | Buna N | Steam, Water | €400.03 | |
| 0600-125TFI-B | 6" | 6" | 6" | 17 1/2" | 6" | 6" | Buna N | Steam, Water | €1,562.59 | |
| 0800-125TFI-B | 8" | 8" | 8" | 18 1/2" | 8" | 8" | Buna N | Steam, Water | €2,732.82 |
