SQUARE D HOM115HM Miniature Circuit Breaker, High Magnetic, 15A, Single Pole
Get it by Tuesday, Mar 31
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Plug In Circuit Breaker |
| Ambient Air Temp. For Operation | 104°F |
| Amps | 15A |
| Amps Rating | 15A |
| Circuit Breaker Type | High Magnetic |
| Depth | 2.98" |
| Electrical Connection | Clamp Terminal For 2 Cables |
| Frame Type | Home |
| Height | 3.13" |
| Mounting Type | Plug In |
| No. Of Poles | 1 |
| No. Of Spaces | 1 |
| Number Of Poles | 1 |
| Ratings | HACR Rated |
| Returnability | Yes |
| Short Circuit Current Rating | 10 kA |
| Tightening Torque | 35.4 lbf.in. @ 0.004 sq. in. to 0.009 sq. in. @ 14 AWG to 8 AWG |
| Voltage Rating | 120/240V AC |
| Voltage Type | AC |
| Width | 1" |
| Wire Size | 14 AWG to 8 AWG, 14 AWG to 10 AWG |
Shipping Info:
| Ship weight (kg) | 0.16 |
| Ship height (cm) | 3.05 |
| Ship length (cm) | 8.38 |
| Ship width (cm) | 8.13 |
| Country of Origin | US |
Product Details:
- Square D HOM115HM miniature circuit breaker installed in HACR (heating, air conditioning & refrigeration) applications for protection against severe current surges causing damage
- Features high magnetic trip unit set at 8 to 10 times the breaker's rating, providing a clear passage to high initial inrush current without tripping, suitable for lighting applications in parking lots & outdoor signs
- Plug-in mounting with clamp terminations allows ease of installation and eliminates loose wiring connection due to vibrations or thermal expansion
- RoHS compliant
Product Variants
| Product | Model | Number Of Poles | Amps | Ac Voltage Rating | Max. Air Rating | Depth | Dc Voltage | Terminal Connection Type | Terminal Connection | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
HOM115 | 1 | 15A | 120V AC | 10 kA At 120V AC | 2.98" | Not Rated | - | Screw Clamp | €13.57 | |
 |
HOM115GFI | 1 | 15A | 120V AC | 10 kA At 120V AC | 2.98" | Not Rated | Screw Clamp | Screw Clamp | €133.36 | |
|
HOM120 | 1 | 20A | 120V AC | 10 kA At 120V AC | 2.98" | Not Rated | Screw Clamp | Screw Clamp | €13.57 | |
 |
HOM120GFI | 1 | 20A | 120V AC | 10 kA At 120V AC | 2.98" | Not Rated | Screw Clamp | Screw Clamp | €133.36 | |
|
HOM130 | 1 | 30A | 120V AC | 10 kA At 120V AC | 2.98" | Not Rated | Screw Clamp | Screw Clamp | €13.57 | |
 |
HOM140 | 1 | 40A | 120V AC | 10 kA At 120V AC | 2.98" | Not Rated | Lug | Lug | €16.90 | |
|
HOM150 | 1 | 50A | 120V AC | 10 kA At 120V AC | 2.98" | Not Rated | Lug | Lug | €16.90 |
