SQUARE D 8536SCO1V02 Magnetic Motor Starter Nema 120v 2p 27a
Item: AF6PFWModel: 8536SCO1V02Cross Ref: 1H511
7 In Stock
Ships within 2 days via
5.00% off
€721.35 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Magnetic Motor Starter |
| Action Type | Nonreversing |
| Amps | 27A |
| Auxiliary Contacts | Without |
| Auxiliary Contacts Included | No Auxiliary Contacts Included |
| Coil Frequency | 50/60 Hz |
| Coil Voltage | 110/120V AC , 120V AC |
| Control Circuit Type | Common |
| Depth | 4.22" |
| Enclosure Type | Open |
| Frequency | 50/60 Hz |
| Height | 6.77" , 6.81" |
| Hp | 3 hp @ 230V AC, 2 hp @ 115V AC |
| Hp @ 1 Ph-240v | 3 hp |
| Hp @ 1 Phase-120v | 2 hp |
| Included Auxiliary Contacts | No |
| Included Pilot Light | No |
| Max. Amps (ac) | 27A |
| Max. Voltage | 600V AC |
| Nema Enclosure Rating | No Enclosure |
| Nema Size | 1 |
| No. Of Poles | 2 |
| Nominal Coil Voltage @ 60hz | 120V AC |
| Operator | Not Available |
| Overall Depth | 4.22" |
| Overall Height | 6.77" |
| Overall Width | 3 1/2" |
| Overload Protection Type | Thermal |
| Overload Type | Melting Alloy 1 |
| Phase | 3 |
| Pilot Light | Without Pilot Light |
| Returnability | Yes |
| Reversing Capability | Non Reversing |
| Sccr | Circuit Breaker 5 kA At 600V AC, Fuse 5 kA At 600V AC |
| Standards | Csa, Ul Listed |
| Starter Style | NEMA |
| Starter Type | NEMA , Non Reversing |
| Terminal Type | Screw Clamp Terminals |
| Thermal Units Required | 1 Melting Alloy Unit (Not Included) |
| Width | 3.5" , 4.53" |
| Wire Termination Type | Screw Clamp |
Shipping Info:
| Ship weight (kg) | 1.78 |
| Ship height (cm) | 11.43 |
| Ship length (cm) | 20.32 |
| Ship width (cm) | 14.73 |
| HS code | 8536504000 |
| Country of Origin | MX |
Product Variants
| Product | Model | Nema Size | Enclosure Type | Height | Coil Voltage | Depth | Action Type | Nema Rating | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
 |
8536SAG12V02ES | 00 | NEMA 1 | 10" | 120V AC | 5 14/25" | Nonreversing | - | - | RFQ
|
 |
8536SBO1V02ES | - | Open | 6.77" | 120V AC | 4.22" | Nonreversing | - | €674.09 | |
|
8536SBO2V02ES | - | Open | 6.77" | 120V AC | 4.22" | Nonreversing | - | €755.85 | |
|
8536SCO3V02ES | 1 | Open | 6.77" | 120V AC | 4.22" | Nonreversing | - | €861.66 | |
 |
8536SAG11V02 | 00 | NEMA 1 | 10" | 120V AC | 5.56" | Nonreversing | - | €976.04 | |
|
8536SAG12V02S | 00 | NEMA 1 | 10" | 120V AC | 5 14/25" | Nonreversing | - | €822.31 | |
 |
8536SAO12V02S | 00 | Open | 6.77" | 120V AC | 4.22" | Nonreversing | - | €710.80 |
