SQUARE D 150SV46A Transformer 120/240VAC 16/32VAC 150VA
Item: AH2NMEModel: 150SV46ACross Ref: 2CM18
7 In Stock
Ships within 2 days via
5.00% off
€588.45 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Buck Boost Transformer |
| Color | Gray |
| Depth | 3 3/4" |
| Enclosure Finish | Powder Coated |
| Enclosure Finish | Powder Coating |
| Enclosure Type | NEMA 3R |
| Frequency | 60 Hz |
| Height | 5" |
| Included Knockouts | Knockouts Included |
| Indoor/outdoor | Indoor, Outdoor |
| Input Voltage | 120/240V AC |
| Insulation Temp. | 221°F |
| Ip Rating | IP54 |
| Knockout Size | 1/2" |
| Mounting | Wall |
| Mounting Location | Wall |
| Nema Enclosure Rating | NEMA 3R |
| Output Voltage | 16/32V AC |
| Overall Depth | 3.75" |
| Overall Height | 5" |
| Overall Width | 4.85" |
| Phase | 1 |
| Power | 150 VA |
| Primary Voltage | 120/240V |
| Returnability | No |
| Secondary Voltage | 16/32V |
| Standards | RoHS |
| Temp. Rise | 131°F , 55°C |
| Va | 150 VA |
Shipping Info:
| Ship weight (kg) | 2.79 |
| Ship height (cm) | 15.24 |
| Ship length (cm) | 16.51 |
| Ship width (cm) | 19.05 |
| Country of Origin | US |
Product Variants
| Model | Height | Depth | Temp. Rise | Phase | Mounting | Enclosure Finish | Indoor/outdoor | Frequency | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| 250SV46B | 5 1/2" | 4.1" | 80°C | 1 | Wall | Powder Coating | Indoor, Outdoor | 60 Hz | €686.51 | |
| 500SV46B | 6 1/5" | 4.7" | 80°C | 1 | Wall | Powder Coating | Indoor, Outdoor | - | €1,074.62 | |
| 750SV46F | 6.7" | 4.7" | 115°C | 1 | Wall | Powder Coating | Indoor, Outdoor | 60 Hz | €1,196.61 | |
| 1.5S46F | 8.3" | 6 3/5" | 115°C | 1 | Wall | Powder Coating | Indoor, Outdoor | 60 Hz | €1,681.24 | |
| 1S46F | - | 5 2/5" | 115°C | 1 | Wall | Powder Coating | Indoor, Outdoor | 60 Hz | €1,480.60 | |
| 2S46F | 9 3/5" | 6 3/5" | 115°C | 1 | Wall | Powder Coating | Indoor, Outdoor | 60 Hz | €2,396.12 | |
| 3S46F | 14 1/2" | 6 1/2" | 115°C | 1 | Wall | Powder Coating | Indoor, Outdoor | - | €3,011.10 |
