SMC VALVES VFR2400-5FZ Solenoid Valve
Item: AL3YDPModel: VFR2400-5FZ
7 In Stock
Ships within 2 days via
€151.15 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Solenoid Valve |
| Actuation | Piloted Solenoid |
| Flow Direction | 4-Way |
| Manual Operation Type | Non-Locking Push |
| Max. Operating Pressure | 130 psi |
| No. Of Port | 5 |
| No. Of Positions | 3 (Exhaust Center) |
| Operating Medium | Air |
| Operating Temp. | 14°F to 122°F |
| Piping Type | Base Mounted Plug In |
| Seal Material | Rubber |
| Series | VFR Series |
| Solenoid Supply Voltage | 24V DC |
Shipping Info:
| Ship weight (kg) | 0.9 |
| Ship height (cm) | 5.08 |
| Ship length (cm) | 7.62 |
| Ship width (cm) | 5.08 |
Product Variants
| Product | Model | Voltage | Actuation | Mounting Orientation | Application | Port Size | No. Of Port | Pressure Rating (mpa) | Type | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
VFR2100-1FZ | 200V AC | Single | Direct | Single Unit | 0.25 | - | 2 MPa to 0.9 MPa | Solenoid Valve | €76.03 | |
 |
VFR2100-5FZ-01 | 24V DC | Single | Direct | Single Unit | 0.25 | - | 2 MPa to 0.9 MPa | Solenoid Valve | €103.29 | |
 |
VFR2100-5FZ-02 | 24V DC | Single | Manifold Base | Unit For Manifold Mounting | - | - | 2 MPa to 0.9 MPa | Solenoid Valve | €103.29 | |
 |
VFR2100-5FZC | 110/120V AC | Single | Manifold Base | Unit For Manifold Mounting | - | - | 2 MPa to 0.9 MPa | Solenoid Valve | €76.03 | |
 |
VFR2100R-5FZ | 24V DC | Single | Direct | Single Unit | 0.25 | - | 2 MPa to 0.9 MPa | Solenoid Valve | €94.37 | |
 |
VFR2110-3D-01 | 110/120V AC | Single | Manifold Base | Unit For Manifold Mounting | - | - | 2 MPa to 0.9 MPa | Solenoid Valve | €92.73 | |
 |
VFR2110-5DZ-02 | - | - | - | - | - | - | - | - | €102.04 |
