SMC VALVES SY3120-5LZ-C4 Valve
Item: AL3UPQModel: SY3120-5LZ-C4
7 In Stock
Ships within 2 days via
€84.38 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Solenoid Valve |
| Actuation | Piloted Solenoid |
| Body Material | Zinc |
| Bracket Type | Without Bracket |
| Flow Direction | 4-Way |
| Lead Wire Length | 300 mm |
| Manual Operation Type | Non-Locking Push |
| Max. Operating Pressure | 130 psi |
| No. Of Port | 5 |
| No. Of Positions | 2 |
| No. Of Solenoids | 1 |
| Operating Medium | Air |
| Operating Temp. | 14°F to 122°F |
| Overall Height | 40.6 mm |
| Overall Length | 76.8 mm |
| Overall Width | 10.8 mm |
| Piping Type | Body Ported |
| Port Size | One Touch Fitting For 4 |
| Port Sizes | 4 Mm Push-To-Connect |
| Seal Material | Rubber |
| Series | SY Series |
| Solenoid Electrical Entry | L Plug |
| Solenoid Power Consumption | 0.35 W |
| Thread Standard | RC |
| Valve Function | Spool |
| Valve Series | SY3000 Series |
| Voltage Suppressor | With Light, Surge Voltage Suppressor |
Shipping Info:
| Ship weight (kg) | 0.9 |
| Ship height (cm) | 5.08 |
| Ship length (cm) | 7.62 |
| Ship width (cm) | 5.08 |
Product Variants
| Product | Model | Overall Length | Overall Height | Overall Width | Price | |
|---|---|---|---|---|---|---|
 |
SY100-61-3-05 | - | - | - | €25.72 | |
 |
SY3440-5LOU | - | - | - | €138.65 | |
 |
SY3140-5LOU | - | - | - | €80.61 | |
 |
SY3240-3LZ | - | - | - | €93.33 | |
 |
SY3140-3LZ | - | - | - | €77.76 | |
 |
SX3140-5LOZ | - | - | - | €85.23 | |
|
SX3140-5MNZD | - | - | - | €69.37 |
