SMC VALVES NCDGBN20-0150 Round Body Cylinder, 20 mm Size, Double Acting Auto Switcher
Item: AM9ZNMModel: NCDGBN20-0150
7 In Stock
Ships within 2 days via
€51.76 /unit
This product can only be shipped in multiples of 2Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Round Body Cylinder |
| Body Material | Aluminum |
| Bore Dia. | 20 mm |
| Cushion Type | Urethane Cushion |
| Hardware Type | Basic Style |
| Included Options | Switch Ready, Magnetized |
| Max. Operating Pressure | 145 psi |
| Min. Operating Pressure | 8 psi |
| Mounting Type | Basic |
| Operating Pressure | 8 psi to 145 psi |
| Operating Temp. | 14°F to 140°F |
| Overall Length | 5.3" |
| Overall Width | 1.02" |
| Piston Action | Double Acting |
| Port Gender | Female |
| Port Size | 0.125 NPT |
| Port Thread Standard | NPT |
| Proof Pressure | 215 psi |
| Rod Gender | Male |
| Rod Size | 1/4 28" |
| Rod Size/thread | 1/4"-28 Male UNF |
| Rod Thread Standard | UNF |
| Rod Type | Single Rod |
| Series | NCG Series |
| Stroke | 1 1/2" |
Shipping Info:
| Ship weight (kg) | 3.15 |
| Ship height (cm) | 7.62 |
| Ship length (cm) | 30.48 |
| Ship width (cm) | 7.62 |
Product Variants
| Product | Model | Type | Price | |
|---|---|---|---|---|
 |
NCGBN40-0400 | - | €77.49 | |
 |
NCGBN40-0600 | - | €83.75 | |
 |
NCGBN40-0800 | - | €89.96 | |
 |
NCGBN50-0200 | - | €96.30 | |
 |
NCGBN50-0400 | - | €104.28 | |
 |
NCGBN50-0800 | - | €120.26 | |
 |
NCG-C025 | - | €15.91 |
