SEALMASTER RB-8 701137 Insert Bearing, 0.5 Inch Dia, Setscrew Locking, Cast Steel/Black Oxide, Standard Felt Seal
Get it by Wednesday, Aug 26
€84.31 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Insert Bearing |
| Ability To Relubricate | No |
| Bearing Insert Finish | Black Oxide |
| Bore Dia. | 1/2" |
| Bore Shape | Straight |
| Cage Material | Molded Nylon |
| Centerline To Front Face | 7/8" |
| Duty Series | Standard Series |
| Dynamic Radial Load Capacity | 2611 lbs. |
| End Cap | No |
| Fixed Vs. Expansion | No |
| Housing Type | Insert Only |
| Htc | 8482.10.5048 |
| Inner Race Heat Treat Method | Zone Hardened |
| Inner Race Length | 1.281" |
| Inner Race Profile | Wide Inner Ring |
| Insert Material | Steel |
| Insert Material Finish | Black Oxide |
| Insert Material Grade | 52100 |
| Inside Ring Outside Dia. | 1.188" |
| Internal Clearance | Standard |
| Locking Type | Set Screw |
| Lubrication Type | Lithium Complex NLGI 2 Grease |
| Max. Operating Temp. | 220°F |
| Max. Speed | 7300 RPM |
| Measure Units | Inch |
| Misalignment Type | Static Only |
| Outer Race Profile | Cylindrical |
| Outer Race Width | 5/8" |
| Outer Ring Land Profile | Standard |
| Outside Race Outside Dia. | 1.85" |
| Overall Width | 1.281" |
| Platform | Gold Line Ball Bearing |
| Precision Rating | Abec 1 |
| Radial Static Load Capacity | 1444 lbs. |
| Radius | 1/25" |
| Replaceable Insert | No |
| Retainer Type | Land Riding Retainer |
| Rolling Element | Ball Bearing |
| Series | Rb Series |
| Set Screw Thread Size | 1/4"-28 |
| Type Of Seal | Felt Labyrinth Seal |
Shipping Info:
| Ship weight (kg) | 0.23 |
| Ship height (cm) | 3.66 |
| Ship length (cm) | 6.05 |
| Ship width (cm) | 6.05 |
| Country of Origin | MX |
Product Variants
| Product | Model | Overall Width | Bore Dia. | Seal Type | Retainer Type | Dynamic Radial Load Capacity | Inner Race Length | Outer Race Width | Outside Race Outside Dia. | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
RB-16 | 1 3/8" | 1" | - | Land Riding Retainer | 2801 lbs. | 1 3/8" | 3/4" | 2.047" | €81.48 | |
 |
RB-15 | 1 3/8" | 15/16" | - | Land Riding Retainer | 2801 lbs. | 1 3/8" | 3/4" | 2.047" | €86.27 | |
 |
RB-19 | 1 5/8" | 1 3/16" | - | Land Riding Retainer | 4381 lbs. | 1 5/8" | 7/8" | 2.441" | €97.08 | |
 |
RB-16C | 1 3/8" | 1" | - | Land Riding Retainer | 2801 lbs. | 1 3/8" | 3/4" | 2.047" | €81.48 | |
|
RB-12 | 1.281" | 3/4" | - | Land Riding Retainer | 2611 lbs. | 1.281" | 5/8" | 1.85" | €79.52 | |
 |
RB-18C | - | - | Single Lip Contact | - | - | - | - | - | €107.95 | |
 |
RB-10 | 1.281" | 5/8" | - | Land Riding Retainer | 2611 lbs. | 1.281" | 5/8" | 1.85" | €79.52 |
