SCHNEIDER ELECTRIC ZB4FW313 Flush Push Button, White, 30 mm Mounting Size, Metallic, Momentary
Get it by Wednesday, Feb 25
€ 24,99 Flat Shipping + VAT € 24,99 flat shipping is applicable on orders with an aggregate weight less than 10kg. Orders exceeding 10kg will be charged default shipping rates.
5.00% off
€32.07 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Head |
| Action | Momentary |
| Action Type | Momentary |
| Basic Material | Metal |
| Bezel Material | Metal |
| Cad Overall Depth | 31 mm |
| Cad Overall Height | 36.6 mm |
| Cad Overall Width | 36.6 mm |
| Color | White |
| Device Presentation | Basic Element |
| Features | Visually Distinct At A Distance, Withstands Harsh Environments |
| Head Material | Metal |
| Head/lens Color | White |
| Ip Rating | IP66, IP67, IP69, IP69K |
| Lamp Bulb Type | No Lamp Module Included |
| Lamp Module Type | No Lamp Module Included |
| Lamp Module Voltage | Module Not Included |
| Lamp Voltage | Dependant On Module Used |
| Legend | No Legend |
| Legend/background Color | No Legend |
| Manufacturer Warranty Length | 18 Months |
| Mounting Diameter | 30.5 mm |
| Nema Enclosure Rating | NEMA 1, NEMA 2, NEMA 3, NEMA 4, NEMA 4X, NEMA 12, NEMA 13 |
| Number Of Indicator Lights | 1 |
| Number Of Operators | 1 |
| Operating Temperature - Maximum | 158°F |
| Operating Temperature - Minimum | -40°F |
| Operator Illumination | Illuminated |
| Operator Material | Metal |
| Overall Depth | 1.22" |
| Overall Height | 1 11/25" |
| Overall Width | 1 11/25" |
| Panel Mounting Hole Diameter | 30 mm |
| Product Datasheet | schneider-electric-xb5fa21.pdf |
| Product Type | Push Button Operators |
| Push Button Style | Flush |
| Replacement Lamps | Module Not Included |
| Resistance Properties | Dust Resistant, Impact Resistant, Vibration Resistant, Watertight |
| Series | XB4 Series |
| Shape Of Signaling Unit Head | Round |
| Terminal Connection | Screw Clamp |
| Type Of Operator | Flush Button |
Shipping Info:
| Ship weight (kg) | 0.06 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 2.54 |
| Ship width (cm) | 2.54 |
| Country of Origin | FR |
Documentation:
Product Variants
| Product | Model | Bezel | Head Material | Legend | Lamp Module Type | Lamp Voltage | Bezel Material | Ip Rating | Basic Material | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
ZB4BW643 | Chrome Plated Metal | Metal | No Legend | No Lamp Module Included | Dependent On Module Used | Metal | IP66, IP69K | Metal | €86.53 | |
 |
9001KR8P1G | - | Metal | Pull To Start, Push To Stop | Transformer | 120V AC | Metal | IP66 | Metal | €427.03 | |
 |
9001KR8P1R | - | Plastic | Pull To Start, Push To Stop | Transformer | 120V AC | Die Cast Aluminum | - | Metal | €427.03 | |
 |
ZB4BW663 | Chrome Plated Metal | Metal | No Legend | No Lamp Module Included | Dependent On Module Used | Metal | IP66 | Metal | €82.16 | |
 |
ZB4BW653 | Chrome Plated Metal | Metal | No Legend | No Lamp Module Included | Dependent On Module Used | Metal | IP66 | Metal | €88.18 | |
 |
ZB4BW11 | - | Metal | No Legend | No Lamp Module Included | - | Metal | IP66 | Metal | €26.10 | |
 |
ZB4FH033 | Chrome Plated Metal | Metal | No Legend | No Lamp Module Included | Dependant On Module Used | Metal | IP66, IP67, IP69, IP69K | Metal | €41.53 |
